wire braid hydraulic hose pipe 1"
- FOB QINGDAO PORT
You May Like
-
EN853 wire braid hydraulic hoses
-
Lowest Price Best Quality Wire Reinforced or Fibre Braided Rubber Hose and Hose Assembly
-
SAE 100 R2AT, DIN EN 853 2SN Hydraulic Rubber Hose
-
DIN/SAE Standard wire braid hydraulic rubber hoses
-
high pressure hydraulic rubber hoses
-
Steel Wire Braided Reinforced Hydraulic Rubber Hose
Product Details
| Place of Origin | Shandong, China | Brand Name | aofenglian | |
| Model Number | hydraulic hose |
Product Description
1.The layer is made of the special kind of synthetic rubber,which has the properties of oil-resistance,heat-resistance and aging-resistance
2.can bear high pressure
3.anti-bending and anti-fatigue
Inside diameter | Reinforcement diameter | Outside diameter | Working Pressure | Alloqable working pressure Mpa | Burst Pressure Mpa | Min.Bend Radius mm | Weight kg/m | |
Mm | Inch | max | max | max | max | min | ||
4.8 | 3/16 | 11.1±0.3 | 16.2±0.3 | 35 | 56 | 140 | 89 | 0.32 |
6.4 | 1/4 | 12.7±0.3 | 17.8±0.3 | 35 | 56 | 140 | 102 | 0.36 |
7.9 | 5/16 | 14.3±0.3 | 19.3±0.3 | 32 | 50 | 128 | 114 | 0.45 |
9.5 | 3/8 | 16.7±0.3 | 21.7±0.3 | 28 | 45 | 112 | 127 | 0.54 |
12.7 | 1/2 | 19.8±0.3 | 24.9±0.3 | 25 | 40 | 100 | 178 | 0.68 |
15.9 | 5/8 | 23.0±0.3 | 28.1±0.3 | 20 | 32 | 80 | 203 | 0.80 |
19.0 | 3/4 | 27.0±0.3 | 32.0±0.3 | 16 | 26 | 64 | 241 | 0.94 |
22.2 | 7/8 | 30.2±0.3 | 35.2±0.3 | 14 | 22 | 56 | 279 | 1.20 |
25.4 | 1 | 34.9±0.3 | 40.4±0.3 | 14 | 22 | 56 | 305 | 1.35 |
31.8 | 1.1/4 | 44.4±0.3 | 51.9±0.3 | 11 | 18 | 44 | 419 | 2.15 |
38.1 | 1.1/2 | 50.8±0.3 | 58.2±0.3 | 9 | 14 | 36 | 508 | 2.65 |
50.8 | 2 | 63.5±0.3 | 70.9±0.3 | 8 | 12 | 32 | 635 | 3.42 |
