SF1225A1 turret press

FOB Price

USD $100,000 - $200,000 / Set

1 Set(Min.Order)

Supply Ability 100 Set / Sets per Month
Port Shanghai
Payment TermsT/T L/C D/P D/A Credit Card PayPal

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition	New	CNC or Not	CNC
Power Source	Other, servo	Place of Origin	Jiangsu, China
Brand Name	EMM	Model Number	SF1225A1
Voltage	380V	Power(W)	30 000
Weight	14	Dimension(LWH)	4995x2736x2250
Certification	ISO 90001	Warranty	one year
After-sales Service Provided	Engineers available to service machinery overseas

Product Description

Specifications

1. high accuracy and efficiency
2. FANUC 0i-P
3. 32 sets tools
4. turret press
5.high automation

SF1225A1 turret press

Product Description

SF1225A1 servo turret press with high accuracy and efficiency. The world’s most advanced technologies integrated. It’s a perfect combination of newest control technology and conventional mechanism. It is an ideal equipment in numerically controlled metal fabrication industry and has such features as high automation, high productivity, stable feature, safe and reliable, save energy, etc.. All these make the machine unique and unmatched in China.

No	Specification	Unit	SF1225A1	SF1250A1	SF1550A1
1	Nominal force	kN	250
2	Max. punch size	mm	F88.9
3	Max. sheet size	mm	1250×2500	1250×5000	1500×5000
4	Max. sheet thickness	mm	6
5	Max. sheet weight	kg	100
6	Punching accuracy	mm	±0.1
7	Ram stroke	mm	32
8	X/Y traverse length	mm	1250/1250	1250/2500	1500/2500
9	Max.punching frequency	min^-1	1200	1200	1200
10	Max. positioning speed	m/min	X=80,Y=80
11	Turret rotation speed	r/min	30
12	Number of tool stations	set	32
13	Number of floating clamps	set	2	3
14	CNC system		FANUC
15	Monitor		10.4²Color monitor
16	Electrical energy(AC 380V )	kVA	30
17	Air consumption	m³/min	0.05
18	Air pressure	MPa	≥0.5
19	Machine dimensions(approx)	mm	4995×2736×2250	4995(5245)×5260×2250
20	Machine weight(approx)	Tons	14	15

Company Information

EMM’s is a comprehensive enterprise dealing economic and technology cooperation that specializes in manufacturing for metal fabrications and distributing of all types of machinery tools Including Industrial Equipment, fabricating equipment, sheet metal equipment and production line machinery.
We are not only trading with customers from domestic and oversea but also providing customers with technical, commutation and after sales support.
Our dedication to the highest quality products and services have establish excellent trade relations with customers from all over the world. EMM’s team memebers includes qualified sales specialists and highly trained technical professional to help provide quick service and the best quality of work in order to meet our customer needs.

Payment terms

1. 100% by T/T;

2. 30% deposit by T/T, the balance paid by L/C at sight;

3. 100% by L/C at sight;

4. 100% by 30, 60 or 90 days usance credit.
