EMH23-40 Mechanical Power Press Manual

FOB Price

US$ 3,500 - 8,000 / Set

1 Set(Min. Order)

Port SHANGHAI
Payment TermsT/T L/C D/P D/A Credit Card PayPal

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition	New	CNC or Not	Normal
Power Source	Pneumatic	Place of Origin	Jiangsu, China
Brand Name	EMM	Model Number	EMH23-40
Voltage	380V	Power(W)	5.5KW
Weight	3590KG	Dimension(LWH)	175013762488
Certification	ISO9001	Warranty	1 YEAR
After-sales Service Provided	Engineers available to service machinery overseas

Product Description

Specifications

EMH23-40 mechanical power press manual
1High-strength frame
2Stable high accuracy
3Slider adjustment mechanism
44Novel desi

EMH23-40 mechanical power press manual

The lathe features good rigidness, stable precision, slider with mechanical overload protection device, and it is safe, reliable and has a long service life.

Technical Data		Unit	EMH 23-35	EMH 23-40	EMH 23-63
Nominal Capacity (Pe)		KN	350	400	630
Nominal Stoke(Sp)		mm	3.5	6	7
Nominal Stoke(S)		mm	80	90	110
Slide Strokes Per Minute(n)		times/ min	60	50	50
Maximum Die Set Height(H2)		mm	290	320	390
Die Height Adjustment(t)		mm	60	65	80
Throat Depth(C1)		mm	220	250	310
Distance Between Uprights(d1)		mm	280	340	420
Slide Bottom Size	L×R(a)	mm	250	300	400
	F×B(b)	mm	220	260	360
Stem hole Size	Dia(d)	mm	40	50	50
	Depth(l)	mm	60	70	70
Bolster Size	L×R(C)	mm	610	700	860
	F×B(D)	mm	400	460	570
Bolster Thickness(H3)		mm	60	65	80
Max. Angle Of Inclination(2)		°	30	30	20
Bolster Surface Height(H1)		mm	815	850	850
Overall Dimensions	F×B(A)	mm	1462	1750	1930
	L×R(B)	mm	1195	1376	1560
	H	mm	2215	2488	2740
Distance Between Foundation Bolts	F×B(a’)	mm	1020	1060	1300
	L×R(b’)	mm	650	750	920
Motor Power		KW	4	5.5	7.5
Weight(Approximate)		Kg	2530	3590	5440
