EB115 hand operated pipe bending machine

FOB Price

US$ 8,000 - 10,000 / Unit

1 Unit(Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition	New	Place of Origin	Jiangsu, China
Brand Name	EMM	Model Number	EB115
Machine Type	Beading Machine	Raw Material	Pipe
Material / Metal Processed	Stainless Steel	Power	Hydraulic
Automation	Automatic	Extra Services	Machining
Certification	CE	After-sales Service Provided	Engineers available to service machinery overseas

EB115 hand operated pipe bending machine

Product Description

Model		EB115	Remark
Max bending capability		Φ115mm×8mm	1. The Minimum bending diameter based on the pipe diameter 2.The Max bending diameter can according to the customer’s requirement 3.The Max length of mandrel can according to customer’s requirement
Max bending radius		R250mm
Min bending radius		R30mm
Max bending angle		190°
Max feeding length		2850mm
Working speed	Bending speed	Max 30°/s
	Rotary speed	Max 160°/s
	Feeding speed	Max 800mm/s
Working accuracy	Bending accuracy	±0.15°
	Rotary accuracy	±0.15°
	Feeding accuracy	±1mm
Bending method		Hydraulic bending
Power of rotary servo motor		1.5kw
Max bending groups		12
Max storing components		330
Motor power		11kw
Oil pressure		12 Mpa
Size		5090 x 1350 x 1230mm
Weight		5500kg

Packaging & Shipping

Related Picture
