Home > Products > Lathe & Machine Center > EMMCHINA S350 Horizontal Lathe Machine
EMMCHINA S350 Horizontal Lathe Machine
- Shanghai
- T/T
You May Like
-
EMMCHINA SK343 Horizontal Cnc Lathe Machine Specification
-
EMMCHINA S327 Horizontal Metal Pipe Specification of Lathe Machine
-
EMMCHINA SY-222 Horizontal Lathe Machine Price
-
EMMCHINA SK130 Horizontal Automatic Pipe Threading Machine
-
EMMCHINA S350 Horizontal Cnc Pipe Threading Machine
-
EMMCHINA SK350 Horizontal New Lathe Machine Price
Product Details
| Condition | New | Type | Horizontal | |
| CNC or Not | Normal | Automatic Grade | Manual | |
| Max. Swing Diameter | 1000mm | Place of Origin | Jiangsu, China | |
| Brand Name | EMM | Model Number | S350 | |
| Voltage | Optional | Power(W) | 37kw | |
| Dimension(L*W*H) | 5000x2160x1750mm | Weight | 15000kgs | |
| Certification | ISO9001 | After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
EMMCHINA S350 horizontal lathe machine
EMMCHINA S350 horizontal lathe machine is mainly used to process inside and outside the pipe thread as well as metric, inch thread. At the same time can also be used as a general ordinary lathe, for shaft, disk cylindrical parts, in the hole and face processing.
Machine is equipped with taper gear, can be used for processing parts with taper.
| Main features | Processed pipe thread diameter range | 330-510mm |
| Max.swing over bed | 1000mm | |
| Max.swing over tool | 610mm | |
| piece length | 1700mm | |
| Max taper | 1:04 | |
| Max stroke of taper bar | 1000mm | |
| Main Drive System | Spindle bore | 520mm |
| Range of spindle speed | 6-205r/min | |
| Steps of reverse spindle speed | 9 | |
| Feed system | Transverse feeding kinds and scope | 32kinds/0.1-1.5mm/r |
| Thread metric No/Range | 32kinds/0.05-0.75mm/r | |
| Thread whitworth No/Range | 23Kinds/1-15mm | |
| Pinth of screw | 2 inch | |
| Longitudinal rapid traverse | 3740mm/min | |
| tool post | Max.travel of compound rest | 300mm |
| Swing angle of tool post | ±90 | |
| Slide plate movement | 0.05mm/case | |
| Max.travel of slide | 0.05mm/case | |
| Tailstock | Dia of sleeve | 100mm |
| Taper of sleeve | Mohs 6 | |
| Sleeve stroke | 300mm | |
| Power system | Main motor | Y180L-4-B337KW 1470r/min |
| Rapid feed motor power | JC021-2-T21.5KW 2850r/min | |
| Cooling system | Cooling pumps | JCB-45 0.15KW 22L/min |
| Machine | Overall dimensions(L*W*H) | 5000×2160×1750mm |
| Weight | 15000kg |
EMMCHINA S350 horizontal lathe machine
Provide Pre-sales Consultant & On-purchase service 8 hr × 6 days per week
1. Reply within 24 hours
2. Provide relevant product information
3. Answer question of customer's requirement
4. Give technical suggestion
Provide After-sales service 24hr × 7days per week
1. Test the machine before shipment
2. Provide technical guidance relate to use the machine
3. Supply one-year warranty period for the machine
4. Provide the spare parts at cost price after warranty period
5. Collect the feedback for the machine working
6. Provide long-term technical assistance.
EMM’s is a comprehensive enterprise dealing economic and technology cooperation that specializes in manufacturing for metal fabrications and distributing of all types of machinery tools Including Industrial Equipment, fabricating equipment, sheet metal equipment and production line machinery.
We are not only trading with customers from domestic and oversea but also providing customers with technical, commutation and after sales support.
Our dedication to the highest quality products and services have establish excellent trade relations with customers from all over the world. EMM’s team memebers includes qualified sales specialists and highly trained technical professional to help provide quick service and the best quality of work in order to meet our customer needs.
EMMCHINA S350 horizontal lathe machine
1. 100% by T/T;
2. 30% deposit by T/T, the balance paid by L/C at sight;
3. 100% by L/C at sight;
4. 100% by 30, 60 or 90 days usance credit.
EMMCHINA S350 horizontal lathe machine
