Automatic sandblasting cabinets 3095

plywooden

Automatic sandblasting cabinets 3095

1) Application

This machine is suitable for sheet metal, flat glass, plastic plates, electric iron, sandwich oven, audio panel, stone, bakelite Products,

 also can be used for electronic (plastic) products deburring

2)Feature

A: The machine is closed -end when working ,no pollute environment

B: Workpiece can be continuous automatic blasting sand , blasting fast ,processing performance is good

C: According the workpiece needs to blasting sand , Conveyor speed with inverter speed control

D:Blasting gun can be fixed or swing according workpiece needs , and can adjust any kind of blasting angle

E: With multiguns to blasting ,just place the work piece on the conveyor belt when operation .automatically sandblasting ,

it's very simple and convenien

F:We can design and manufacture different automatic sandblast machine according to customer's requirments.

3) Technical
Machine material :2.5mm-10mm welded steel plate
1.Blasting room size : 1500*1100*1000mm (L*W*H)
2.Outside size of host: 4000*1400*2000mm(L*W*H)
3.Dust collector :1500*1500*2500mm(L*W*H) Fan motor :5.5KW
4.Automatic transmission mechanism: 1.5KW 220V 60HZ [speed inverter control]
5.Transmission V- belt :1000*3600mm
6.Transmission speed :0.5-3m/min
7.Automatic gun rack :0.75KW 220V (speed inverter control)
8.Light :lamp 3pcs .18W
9.Blasting gun number :12pcs
10.View :2 glasses
11.Bucket of Sand :3pcs
12.Door : 2pcs .door size 800*700mm
13.Belt loading weight : less than 120kg
14.Total power :about 9.8KW
15.Total weight :1850kg
16.Suitable abrasive :30-120mesh glass beads
17.Required compressor :should more than 7bar ,about 15m3/min

4)suitable abrasive:
