Rice Harvester Chains
- ningbo
- Credit Card
You May Like
Product Details
| Use | Harvesters | Place of Origin | Zhejiang, China | |
| Brand Name | dongsheng, huangli | Model Number | A |
COLOR BOX/ NORMAL BOX+ STEEL PALLETS / WOODEN CASES
Product Description
High quality alloy material ensure the harden of hole-making model, we change the model very often no matter whether the model attrite or not , so we can make sure the bright area of roller chain plate inner hole. Its known to all that good bright area of inner hole good for anti fatigue.
Our Dongsheng chains fit standard of ISO, ANSI, DIN, and JIS, its heat treatment is advanced and material is selected alloy steel. The products have been sold to the whole country and Europe, American, Middle-east and South-East Asia.
The Chain technic treatment is as below:
Shot peening
Bluing
Phosphating
Nickel-plated
Zincing
Heat treatment
Carburizing
Quenching
Tempering
Oiling
Greasing
| Pitch | Roller diameter | Width between inner plates | Pin diameter | Pin length | Tooth angle | Inner Plate depth | Piate thickness | Aver age tensile strength | Ultimate tensile strength | Type form | ||||
| Chain No. | P | d1 max | b1 min | d2 max | L max | L c max | a | h1 | h2 max | H | T max | Q min | Q0 | |
| mm | mm | mm | mm | mm | mm | mm | mm | kn | kn | |||||
| 3318.5-B1.60-70 | 33 | 10.1 | 18.5 | 7.0 | 29.0 | 31.0 | 70 | 10 | 13 | 38 | 1.60 | 19.60 | 22.50 | B |
| 3325-B2.03-90 | 33 | 10.1 | 25.0 | 7.0 | 37.0 | 39.5 | 90 | 10 | 13 | 38 | 2.03 | 19.60 | 24.00 | B |
| 3325-B1.70-70 | 33 | 10.1 | 25.0 | 7.0 | 35.6 | 37.6 | 70 | 10 | 13 | 38 | 1.70 | 19.60 | 22.50 | B |
| 3325-B2.0/1.6-70 | 33 | 10.1 | 25.0 | 7.0 | 36.8 | 39.0 | 70 | 10 | 13 | 38 | 2.0/1.6 | 19.60 | 23.00 | B |
| 3325-B2.0/1.6-90 | 33 | 10.1 | 25.0 | 7.0 | 36.8 | 39.0 | 90 | 10 | 13 | 38 | 2.0/1.6 | 19.60 | 23.00 | B |
| 3325-A1.6-60 | 33 | 10.1 | 25.0 | 7.0 | 35.5 | 37.7 | 60 | 10 | 13 | 43 | 1.60 | 19.60 | 22.50 | A |
| 3325-A1.6-90 | 33 | 10.1 | 25.0 | 7.0 | 35.5 | 37.7 | 90 | 10 | 13 | 38 | 1.60 | 19.60 | 22.50 | A |
| 3325-A1.6-70 | 33 | 10.1 | 25.0 | 7.0 | 35.5 | 37.7 | 70 | 10 | 13 | 38 | 1.60 | 19.60 | 22.50 | A |
| 3330-B1.7-60 | 33 | 10.1 | 30.0 | 7.0 | 40.3 | 42.7 | 60 | 10 | 13 | 43 | 1.70 | 19.60 | 22.50 | B |
| 3330-B1.7-70 | 33 | 10.1 | 30.0 | 7.0 | 40.5 | 42.8 | 70 | 10 | 13 | 38 | 1.60 | 19.60 | 22.50 | A |
| 3330-A1.6-60 | 33 | 10.1 | 30.0 | 7.0 | 40.5 | 42.8 | 60 | 10 | 13 | 43 | 1.60 | 19.60 | 22.50 | A |
| 3340-B2.0/1.6-70 | 33 | 10.1 | 40.0 | 7.0 | 51.8 | 54.0 | 70 | 10 | 13 | 38 | 2.0/1.6 | 19.60 | 23.00 | B |
| 3340-B1.6/1.2-90 | 33 | 10.1 | 40.0 | 7.0 | 49.2 | 52.5 | 90 | 10 | 13 | 38 | 1.6/1.2 | 19.60 | 22.00 | A |
| 3350-B1.6-70 | 33 | 10.1 | 50.0 | 7.0 | 60.2 | 62.5 | 70 | 18 | 10 | 43 | 1.60 | 19.60 | 22.50 | A |
| 3358-B1.6-90 | 33 | 10.1 | 58.0 | 7.0 | 72.2 | 72.2 | 90 | 18 | 10 | 38 | 1.60 | 19.60 | 22.50 | B |
| 3540-B1.6-70I | 35 | 10.1 | 40.0 | 7.0 | 52.5 | 52.2 | 70 | 18 | 10 | 43 | 1.60 | 19.60 | 22.50 | B |
| 3540-B1.6-70II | 35 | 10.1 | 40.0 | 7.0 | 52.5 | 52.5 | 70 | 18 | 10 | 35 | 1.60 | 19.60 | 22.50 | B |
| 3558-B2.03-90 | 35 | 13.2 | 58.0 | 9.4 | 70.0 | 72.3 | 90 | 15 | 18 | 47 | 2.03 | 22.54 | 27.10 | B |
phone:0086-579-87383203
skype:wendylove0312
web:www.dschain.en.china.cn
Company Profile
Jake Import and Export Co., Ltd was founded as the international trade department of ZheJiang DongSheng Chain Co.,Ltd. At the basis of its self-managed projects of roller chain,including agriculture machinery chain,industrial chain,conveyor chain,motorcycle accessories,bicycle chain and spocket etc. We have combined the advantage of low factory price,stable quality performance with professional trade skill to realize Industry and trade integration. Now Jake has a professional sales team of 20 staff and a complete customer service system.Workers are specially assigned for each process of order,production arrangement,producing progress,quality control,product inspection,customs declaration and logistics. All in all,Jake is a realiable business partner.Both the factory and sales company in domestic and foreign market are approved by the field authentication fo INTERTEK in 2011.
