Home > Products > Water pump > Competitive price 0.5HP QB60 electric Water Pump
Competitive price 0.5HP QB60 electric Water Pump
- 5000 Set / Sets per Month
- Fuzhou Port
- T/T
You May Like
Product Details
| Place of Origin | Fujian, China | Brand Name | Saint Meilan | |
| Model Number | QB series | Theory | Vortex Pump | |
| Structure | Single-stage Pump | Usage | Water | |
| Power | Electric | Standard or Nonstandard | Standard | |
| Fuel | Diesel | Pressure | Low Pressure | |
| Application | Other, Water |
Product Description
Specifications
QB60 Clean Water Pump1 High quality
2 excellent suction
3 reliable, safe
4 CE ,TUV and SONCAP
ATLAS QB60 High quality Competitive price Clean Water Pump
| SPECIFICATIONS |
| MODEL | POWER | MAX.FLOW l/min | MAX.HEAD m | SUCT m | INLET/ OUTLET | G.W kg | PACKING DIMENSION cm | |
| KW | HP | |||||||
| QB-60 | 0.37 | 0.5 | 35 | 35 | 9 | 1"x1" | 6 | 28.5x17x17.5 |
| QB-70 | 0.55 | 0.75 | 45 | 50 | 9 | 1"x1" | 10 | 32.5x18x21 |
| QB-80 | 0.75 | 1.00 | 50 | 55 | 9 | 1"x1" | 11 | 32.5x18x21 |
QB and Jet series are suitable for pumping clean water. They are particularly suitable for domestic applications such as supply water from well, pool etc, the automatic distribution of water by surge tanks and pressure switch, gardening, and increasing of water pressure.
MODEL | Max. | H.Max. | Suct.Max. | Power | Volt. | Freq. | Speed | Pump dia. | Net | Overall Dimension |
JET-60S | 46 | 35 | 9 | 460 | 220 | 50 | 2850 | 25X25 | 12.3 | 390x200x210 |
JET-80S | 48 | 40 | 9 | 600 | 220 | 50 | 2850 | 25X25 | 12.8 | 390x200x210 |
JET-100S | 50 | 45 | 9 | 750 | 220 | 50 | 2850 | 25X25 | 13.4 | 390x200x210 |
Pump body: Cast iron
Insulation class: B/F
Impeller: Brass
Protection class: IP44/IP54
Shaft: 45# steel/stainless steel
Motor with thermal protector
Mechanical seal: Stainless steel/Carbon-ceramic
