60Hz 24KW/30KVA Diesel Generator Powered By Deutz

FOB Price

USD $2,000 - $3,060 / Set

1 Set(Min.Order)

Port Fuzhou Port any port in China
Payment TermsT/T

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Fujian, China	Brand Name	Deutz, Deutz
Model Number	SMAD, SMAD	Output Type	AC Three Phase
Speed	1800RPM	Frequency	60HZ
Rated Power	50kva--1000kva	Rated Voltage	220V/380V, 230V/400V, 240V/415V
Rated Current	25-2000A

Product Description

Specifications

60Hz 24KW/30KVA Diesel Generator Powered By Deutz
1.1800rpm
2.F3L912/Stamford Pl144E
3.ATS,AVR
4.Deep Sea Controller 5110

60Hz 24KW/30KVA Diesel Generator Powered By Deutz

Technical Data
GROUP	Manufacturer				Saint Meilan
	Model				DAS32-60
	Frequency				60HZ
	Power	Standby Power			25KW 32kVA
		Prime Power			24KW 30kVA
	Open type		Dimension(LWH)	mm	13007731015
			Weight	Kg	475
DIESEL ENGINE	Engine Manufacturer				Deutz
	Model				F3L912
	Cylinder Arrangement				3 in line
	Governor/Class				Mechanical/Electric
	Fuel spray pattern				Direct injection
	Start-up method				12/24V,electric
	Battery capacity				70~100A/hr
	Aspiration				Natural
	Cooling mode				Air-cooled
	Bore and stroke				100 × 120mm
	Displacement				2.828L
	Lubrication oil capacity				11L
	Engine Prime Power at 1500rpm				28kWm
	Engine Standby Power at 1500rpm				30kWm
	Fuel consumption				≤249
Alternator	Manufacturer				Stamford
	Model				PI144E
	Rated Voltage				440V
	Voltage regulation mode				Auto
	Exciter Type				Brushless self exciting
	Power factor				0.8
	Rated current				45A
	Insulation class				H
	Protection class				IP23
	Standards				IEC34-1
	Max. altitude				1000m

DEUTZ generator set selects F series air cooled DEUTZ engine from Sino-Germany joint venture companies in China. It also includes alternator, base frame, connecting flange, fuel tank, and control system etc.
1. The characteristic of F series air cooled DEUTZ engine:
1) The average temperature of the cylinder cover can be up to 170°C, which is higher than ambient air temperature, so it is suitable for high temperature area
2) It doesn’t need anti-frozen liquid, it can be well started and work reliably even at -35°C,
3) It doesn’t have water cooled system, so it doesn’t have the troubles, such as erosion, rust, water dreg. Its trouble is lower than that of water cooling diesel engine by 27%.
4) Cylinder wall is suitable for high temperature and fast rising temperature, so its acidity erosion and friction are less than that of water cooled engine.
5) It has fast warm and good start-up function, so that it can be able to enter loading status in 5-6 minutes.
6) With high reliability, less trouble, long service life and easy operation, it can run well in normal technical maintenance Gensets can be open type or soundproof (silent) type.
