Home > Products > Diesel Generator Set > 5kva - 10kva Summer Power Supply Diesel Engine Generator
5kva - 10kva Summer Power Supply Diesel Engine Generator
USD $200 - $500
/ Set
1 Set(Min.Order)
- 1000 Set / Sets per Month
- Fuzhou Port
- T/T
You May Like
-
Deutz air-cooling engine original Germany F4L912
-
Stock 17kva F4L914 Deutz air-cooling basic and canopy Generator
-
30kva Deutz air-cooling open and canopy Generator
-
60kva 48kw Deutz BF4M2012 UCI224E water turbine cooling Generator
-
SMLD250 200kva Deutz Generator AMF Power Plant
-
300kva Deutz TBD234V8 water-cooling open and canopy Generator
Product Details
| Place of Origin | Fujian, China | Brand Name | Saint | |
| Model Number | SMLD6500SE, Saint Meilan | Output Type | AC Three Phase | |
| Speed | 1500RPM/1800RPM | Frequency | 50/60Hz | |
| Rated Power | 5kva--1250kva | Rated Voltage | 110V/240V, 220V/380V, 230V/400V, 240V/415V | |
| Rated Current | 20-2000A |
Product Description
Specifications
5kva - 10kva Summer Power Supply Diesel Engine Generator1 CE approved
2 Noise 65 db (7 meters)
3 Inn,room,etc
4 Reliable
5kva - 10kva Summer Power Supply Diesel Engine Generator
For Inn,Restaurant,Home air-conditioner,etc Summer Power Supply
Open and Soundproof
| DIESEL GENERATORS | ||||
| OPEN FRAME Series | ||||
| Model | XDG2200/E | XDG3600/E | XDG5000/E | XDG6000/E-3 |
| FOB Fuzhou port,China | 200-300 | USD200-300 | USD300-350 | USD300-400 |
| Frame Type | Open Type | Open Type | Open Type | Open Type |
| Frequency(Hz) | 50 / 60 | 50 / 60 | 50 / 60 | 50 / 60 |
| Voltage(V) | 110~240 | 220/380 110/190 | ||
| Rated Power (kVA) | 1.8 / 2.0 | 2.8 / 3.0 | 4.5 / 5.0 | 4.5 / 5.0 |
| Max.powert(kVA) | 2.0 / 2.2 | 3.0 / 3.3 | 5.0 / 5.5 | 5.0 / 5.5 |
| Phase | Single | 3-phase | ||
| Power factor | 1.0 | 1.0 | 1.0 | 0.8 |
| Diesel Engine Type | 170F/FE | 178F/FE | 186F/FE | 186F/FE |
| Max. Power Output (hp) | 4.0HP | 6.0HP | 9.0HP | 9.0HP |
| Diesel Engine Type | Air-cooled, 4-stroke,Vertical,Single-cylinder, Direct injection combustion. | |||
| Bore*stroke(mm*mm) | 70*55 | 78*62 | 86*70 | 86*70 |
| Displacement (cc) | 211 | 296 | 406 | 406 |
| Compression rate | 20:01 | 20:01 | 19:01 | 19:01 |
| Ignition System | Explode Ignition | |||
| Lube oil system | Pressure splash Type | |||
| Starting System | Recoil or Electric | |||
| Lube oil capacity(L) | 0.75 | 1.1 | 1.65 | 1.65 |
| Fuel Tank Capacity(L) | 12.5 | 12.5 | 12.5 | 12.5 |
| Dimension(L*W*H)(mm) | 630*475*560 | 700*475*580 | 720*490*620 | 720*490*620 |
| N.W/G.W (kg) | 60/65 | 78/83 | 91/96 | 9/96 |
| 20ft(set) | 180 | 160 | 105 | 105 |
silent :72 pieces for 20ft container
open:108 pieces for 20ft container
Certificate:SONCAP,CE,COI,SGS,BV,EPA
Characteristics:
1. Powered by air-cooled 4-stroke diesel engine.
2. 12-volt DC auxiliary charging (car/boat battery).
3. Injection nozzle with electric control clique.
4. Low oil alert system shuts down the engine automatically.
5. Wheels for easy move.
6. Key operated ignition switch for the standard electric starter.
7. Standard equip with 24Ah dry battery.
8. Hydraulic-Magnetic circuit breaker.
Package
Pallet
Diesel Generator,Gasoline Pump,Water Pump,Protable Genset,Moving Trailer
