Home > Products > Alternator / Generator > stc boat 3kw upto 50kw motor generator
stc boat 3kw upto 50kw motor generator
- any port in China
- T/T Credit Card
You May Like
Product Details
| Place of Origin | Fujian, China | Brand Name | generator | |
| Model Number | st-5 | Output Type | AC Single Phase | |
| Speed | 1500rpm | Frequency | 50hz | |
| Rated Power | 5kw | Rated Voltage | 220v | |
| Rated Current | 22.7A |
Product Description
Specifications
motor generator1.Metal Fan,Sealed Bearings
2.Balanced rotor,copper stator winding
3.v b pulley, AVR installed
4.50/60 hz
stc boat 3kw upto 50kw motor generator
which are mainly designed to serve as power generating
unit of small capacity which supply electricity for lighting purpose in ships as for household electric devices used in towns or villages
It can used with a diesel engine ,that is a diesel generator set
The construction of the generators is of drip-proof, salient pole rotating field self excitation and constant voltage type
Excellent appearance, consolidate in construction and easy to maintain.
Output: 1kw to 50kw
.....................................................................................................................................
Environment Conditions:
Under the following environment,the generator could run continuously:
1.Altitude: not exceed 1000m.
2.Cooling air temperature: 258~313K(-15~40).
3.Relative air humidity :not exceed 90%.
..........................................................................................................................
| Model | Output | Current(A) | pole | speed(r.p.m) | |
| kw | KVA | ||||
| STC-3 | 3 | 3.8 | 5.4 | 4 | 1500 |
| STC-5 | 5 | 6.3 | 9 | ||
| STC-7.5 | 7.5 | 9.4 | 13.5 | ||
| STC-10 | 10 | 12.5 | 18.1 | ||
| STC-12 | 12 | 15 | 21.7 | ||
| STC-15 | 15 | 18.8 | 27.1 | ||
| STC-20 | 20 | 25 | 36.1 | ||
| STC-30 | 30 | 37.5 | 54.1 | ||
| STC-40 | 40 | 50 | 72.2 | ||
| STC-50 | 50 | 62.5 | 90.2 | ||
1. we get China Coerciveness Certificate, Export Quality Certificate and IS09001 , CE certificate .
2. terms of payment, we accept 30% TT advance and the balance 70% payment will be paid after send the B/L copy by email to the buyer . Or we can also accept L/C 30days and L/c 60 days
