high speed 3D CX1520 Water Jet Cutting machine for cutting stainless steel, aluminium sheet and marble
- 50 Set / Sets per Month
- FOB Qingdao
- T/T
You May Like
-
CX-1530 China CNC water jet cutting machine/ Water Jet Cutter/ with imported intensifier pump
-
CX-1520 Water Jet Cutter/ CNC water jet cutting machine with imported intensifier pump
-
CX-2040 Water Jet Machine/ waterjet cutting machine with high pressure imported intensifier pump
-
CX-1530 Waterjet Cutter with imported intensifier pump
-
CX-1520 Water Jet Machine with imported intensifier pump
-
China JSX-1520 Water Jet Cutting Machine Taiwan HIWIN ball screw
Product Details
| Brand Name | Superstar | Model Number | CX-1520 | |
| Rated Power | 30KW | Weight | 500kg | |
| Warranty | One year |
Product Description
Specifications
high speed 3D Water Jet Cutting machine1.stable pressure 440Mpa within 24 hours
2. high speed, cutting thick materials
Product | CX1520 Water Jet Cutting machine |
Price | FOB Qingdao *** USD |
MOQ | 1 SET |
Warranty | One year |
Technical specifications
Model | CX-1520 |
Machine size | 2000mm*2500mm |
Working size | 1500mm*2000mm*350mm |
Control system | Water jet system America Match 3 |
Reposition precision | ±0.1mm |
Cutting precision | ±0.25mm/TBI Graphics input |
The cutting speed (mm/min)and cutting thickness
material | thickness | Cutting speed(mm/min) cutting pressure(300MPa) | Cutting speed(mm/min) cutting pressure(380MPa) |
marble | 20 | 300 | 400 |
30 | 200 | 300 | |
granite | 20 | 250 | 300 |
30 | 150 | 200 | |
Vetrified tiles | 10 | 600 | 850 |
28 | 120 | 200 | |
glass | 6 | 800 | 1000 |
10 | 600 | 800 | |
19 | 350 | 500 | |
laminated glass | 21 | 400 | 600 |
foam | 20 | 5000 | 7000 |
50 | 2000 | 3000 | |
80 | 1500 | 2000 | |
Car interior (carpet) | 3 | 2000 | 2700 |
Stainless steel | 1 | 800 | 1100 |
3 | 400 | 600 | |
6 | 140 | 200 | |
10 | 110 | 170 | |
16 | 80 | 110 | |
20 | 50 | 80 | |
30 | 25 | 40 | |
55 |
| 20 | |
65 |
| 10 | |
copper | 3 | 600 | 1000 |
5 | 450 | 700 | |
aluminium | 10 | 300 | 450 |
20 | 180 | 240 | |
30 | 100 | 150 | |
70 |
As the hardness of gold, silver and copper is similar, this machine can satisfy your request definitely.
Features:
1. Adopt imported intensifier pump to pressurize normal tap water to 500Mpa, provide a stable pressure 440Mpa within 24 hours.
2. Adopt three-phase 75KW 160L hydraulic stabilizing system, the maximum displacement of accumulator is 3.7L/min, two in one system 5μm water filter.
3. Taiwan HIWIN ball screw with a protective system insures the accuracy of processing.
4. Y axis adopts double driver system, high accuracy, stable processing.
5. Adopt ball screw and orbits of international bands with high quality; ensure high-precision machining, smooth transitions, and a long lifespan.
Gantry type:
1200*1200mm 500MPA servo driver TBI
1500*2000mm 500MPA servo driver TBI
1500*2500mm 500MPA servo driver TBI
2000*4000mm 500MPA servo driver TBI
Arm type:
1200*1200mm 400MPA servo driver TBI
1500*2000mm 400MPA servo driver TBI
1500*2500mm 500MPA servo driver TBI
2000*4000mm 500MPA servo driver TBI
Guarantee:
Electric parts - ONE year
High-pressure cylinder - THREE years
Accumulator - FOUR years
High-pressure sealing ring - One year
