Home > Products > Metal Mould Machine > CX400 cnc router machine for aluminum and iron
CX400 cnc router machine for aluminum and iron
- 100 Set / Sets per Month
- qingdao
- T/T
You May Like
Product Details
| Condition | New | Place of Origin | Shandong, China | |
| Brand Name | Superstar | Model Number | CX400 | |
| Rated Power | 1840w | Engraving Speed | 8m/min | |
| Main Axle Rotational Speed | 24000/rpm | Feeding Height | 300mm | |
| Milling Cutter Diameter | 3.175/4/6mm | Application | metal | |
| Dimensions | 480*480mm | Weight | 1200kg | |
| Certification | CE ISO9001 SGS | Warranty | 1 year | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Specifications
cnc router machine for aluminum1.imported square linear guide rail
2.water cooling spindle
3.stepper/servo motor
1.imported square linear guide rail
2.water cooling spindle
3.stepper/servo motor
metal mould machine
Application:
Our CNC Metal Engraving Machine helps in efficient engraving on iron, steel, bronze board and aluminum. The CNC Metal Engraving Machine is used for engraving letter and relied designs. We provide the CNC Metal Engraving Machine at reasonable prices. The CNC Metal Engraving Machine is made from good-quality components, which make it durable and performance-oriented.
No. | Name |
| Parameter | No. | Name | Unit | Parameter |
1 | Working table size | mm | 480*480 | 9 | Working precision | mm | ±0.01/300 |
2 | X,Y,Z working area | mm | 400*400*110 | 10 | Positioning precision | mm | 0.012 |
3 | Working table loading | kg | 95 | 11 | Spindle power | kw | 1.5 |
4 | Gantry width | mm | 530 | 12 | Drive system |
| AC servo |
5 | Machine weight | kg | 1100 | 13 | Z height | mm | 250 |
6 | Spindle rotating speed | rpm | 24000 | 14 | Working table deformation under pressure |
| <0.03mm(95kg) |
7 | Max. engraving speed | mm/min | 6000 | 15 | A axis rotating angle | Degree | 360 |
8 | Machine diamention | mm | 1100*1050*1600 | 16 | A axis precision |
| ±30 |
17 | Packaging size | mm | 1650*1650*2200 | 18 | Whole weight | kg | 1350 |
3.Standard configuration
1. HIWIN C3 level precise ball screw made in Taiwan(for three axis) | 7. R+W flexible couplings |
2. NSK P4 level bearings( for three axis) | 8.Splitter made in Taiwan |
3. Imported limit sensor(for three axis) | 9.Stainless steel protecting hoods( for X/Y axis) |
4. HIWIN high precision guide rail( for three axis) | 10.High speed precise spindle made in China |
5. Panasonic servo motor 400W (four axis) | 11.Precise auto aligning device made in Taiwan |
6. control system: SYNTEC EZ4 | 12.Handwheel with four files |
Jinan Jinshengxing Machinery Manufacture Co., Ltd. is a professional company in researching, developing and manufacturing CNC routers. Our company devotes to carving CAD / CAM technology and CNC numerical control technology research and development. We have made great progress in the precise CNC router design theory and craft technology
Delivery TIME: 15 days after receiving the deposit
Payment Terms: T/T 50% in advance, then 50% when you receive the copy of the B/L of the shippment
Packaging: Strong smoke freed wooden box
Delivery and Transport:
1.FOB----The nearest port is Qingdao port,and we can also delivery
the machine to other port according to your request.
2.CIF-------Please tell me what’s the destination port when you need CIF price.
3.If you need others, please tell me and I’m pleasure to do for you.
