Home > Products > CNC Router with ATC > wood cnc router with 9KW atc spindle (8 atc tools in back of the table)
wood cnc router with 9KW atc spindle (8 atc tools in back of the table)
Negotiable
/ Set
1 Set(Min.Order)
- Qingdao port China
- T/T
You May Like
-
1325 cnc wood engraving machine with ce
-
Hot sale 0.05mm precision cnc router with ATC (SKM25)
-
ATC woodworking machine SKM25
-
High quality good price classic furniture cnc woodworking carving machine
-
woodworking machinery SKM25 mainly used for wood door
-
combination woodworking machines with auto tool changer M25H
Product Details
| Condition | New | CNC or Not | CNC | |
| Place of Origin | Shandong, China | Brand Name | Super Star | |
| Model Number | M25H |
Product Description
Specifications
wood cnc router with 9KW atc spindle1.8 tools in line
2. 9KW air cooling spindle
3.Taiwan LNC control
4.Vaccum table
M25H wood cnc router with 9KW atc spindle (8 atc tools in back of the table)
Feature:
- Adopt linear-square orbit, whole machine is welded with seamless steel structure, can bear heavy loading.
- Ball screw for z axis and gear-wheel for x and y axis
- TAIWAN LNC control system. Intelligent anti-transgress-process protection system. The function can prevent from crashing when the design zone is beyond the process zone.
- Vacuum table and dust collector system with 6 zones separately control, auto tool changing system. No oil pump and dust cover.
- China domestic made 8kw water cooling spindle(optional:8kw HSD Italy air cooling spindle).
- Auto oiling,8 tools changer, imported servo motors and inverters, 12 cutters and 4 collects
Technical Parameter:
X working area | 1300mm |
Y working area | 2500mm |
Z working area | 380mm |
Table size | 1300*2500mm |
Traveling positioning accuracy | ±0.05mm |
Repositioning positioning accuracy | ±0.05mm |
Table surface | By suction |
X Y Z structure | XY gear wheel, Z ball screw |
Max. power consumption(without spindle) | 2.8kw |
Max. Rapid travel rate | 50000mm/min |
Max. working speed | 25000mm/min |
Spindle power motor | 5.5kw |
Spindle speed | 0-24000r/min |
Drive system | Servo |
Working voltage | AC380V/60HZ |
Command | G-code |
Samples:
