Automatic Water Slot Milling Machine for PVC Profile

Place of Origin	Shandong, China		Brand Name	SOLTERRA
Model Number	SCXZ2		Condition	New

Specifications

1.Over 20 years experience
2. HIGH QUALITY & COMPETITIVE PRICE
3. ISO9001:2008 Certification
4. India branch office



Automatic Water Slot Milling Machine

 for PVC Profiles



Established since 1991, Jinan Liaoyuan Machinery Co., Ltd. is a professional manufacturer producing machines for door and window industry & curtain wall industry. We have passed the ISO9001:2008 Certification. We are the right supplier for you!



Equipment  Features:

1. Milling all kinds of water slots and air pressure balance grooves.

2. Two set of three-axis milling heads layout along the machine.

3. Clamping one time to finish water slot processing.

4. High efficiency, suitable for mass production.



5. Special feeding system, do not need special maintenance, high milling quality.

6. Convenient adjustment for the cutter location to meet different kinds of profile.

7. Water slot milling length adjustable within 100mm, wide adaptability.

8. Adopt linear bearing motion to ensure the processing precision.



Main Specification and Technical Parameters:

Model                                                           SCXZ2

Input voltage                                               220V/50Hz

Input power                                                 2.28kw

Air pressure                                                0.5-0.8Mpa

Air consumption                                         50 L/min

Main-shaft revolution                                 25000r/min

Cutter diameter                                          Φ5mm Φ4mm

Slot depth                                                    30mm

Slot length                                                   0-100mm

Overall dimension                                     3800*1200*1800mm

Weight:                                                         900kg

If there is any questions or doubts, please feel free to contact me.
