Home > Products > Semi-Automatic Block Making Machine > Manual Concrete Block Making Machine From China HYM4-30
Manual Concrete Block Making Machine From China HYM4-30
- xiamen
- T/T
You May Like
-
Semi-auto-concrete Brick Machine From China QT4-30
-
QT4-40 Concrete Block Making Machine HYM
-
Simple Concrete Block Making Machine Produce Hollow Brick
-
Semi-auto and Small Capacity Fly Ask Brick Making Machine in India
-
Fly Ash Colorful Block Machinery Low Cost and Easy Operated(4-25)
-
HYM Manual Color Plaza Stone Making Machine
Product Details
| Condition | New | Type | Hollow Block Making Machine | |
| Brick Raw Material | Concrete | Processing | Brick Production Line | |
| Method | Hydraulic Pressure | Automatic | No | |
| Capacity | 1500pcs/8 hours | Place of Origin | Fujian, China | |
| Brand Name | HYM | Model Number | QT4-30 | |
| Voltage | 380V | Power | 19.9KW | |
| Dimension(L*W*H) | 2700X1000X2200MM | Certification | ISO90001.2009 | |
| Warranty | one year | After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Specifications
Manual concrete block making machine from china HYM4-30price concrete block machine
used concrete block making machine for sa
Manual concrete block making machine from china HYM4-30
price concrete block machine
used concrete block making machine for sales
1.Main technical parameters
Cycle Time | 20-30S | Vibration Type | hydraulic vibration |
Total Power | 19.9kw | Oil pump motor | Y132S2-4N+5.5kw |
Vibration Frequency | 3800-4500(times/sub) | Side cylinder | 63*250Φ40 |
Pallet Size | 850×560×20(mm) | Machine Size | 2700x1500x2200mm |
Rated Pressure | 8.5(mpa) |
| |
2.Brick Sizes and capacity:
Brick | Sizes | Output/ mould | Output/Shift(8hours) | picture |
Hollow Block | 390x190x190mm | 4 | 3456-4320 |
|
Color brick | 200x100x60mm | 15 | 11520-14400 |
|
Solid brick | 240x115x51mm | 26 | 19920- 28000 |
|
Multi-holes block | 240x115x90mm | 12 | 9600-14400 |
|
Manufacturing Technique
- Production Process
| Mixing system |
| Conveyor Belt
|
| Block Making System
|
2.Production Flow Introduction
Mixing system :Mixer will mixingvarious raw materials to mixed, that to be a mixture or appropriate consistency machine.
Conveyor Belt:Conveyor Belt is supply the Stir well materials to timing feed in the system in the concrete block machine.
Block Machine:Block Machine is pressing raw material forming, change different mold production various specifications of cement block product
3,Production Main Processing Equipments
Technical Characteristic & Paramete
No. | Name | Technical Parameter | Introductions | product display | |
1 | HY-Conveyor Belt | Power | 2.2KW | Conveyor Belt is supply the Stir well materials to timing feed in the system in the concrete block machine.
|
|
Length | 6M | ||||
Revolvingspeed | 1430r/min | ||||
Frequency | 50Hz | ||||
2 |
HY-Block Making System | power | 19.9kw | Block Machine is pressing raw material forming, change different mold production various specifications of cement block product
|
|
Vibration frequency | 3800~4500r/min | ||||
Daily Capacity (8 hours) | |||||
Blocks | 2800-3800 | ||||
Paver bricks | 8600-11500 | ||||
Interlocking block | 10800-14400 | ||||
Solid bricks | 18700-2500 | ||||
Pallet size | 850×560×20(mm) | ||||
Dimension | 2700x1500x2200mm | ||||
| JS350 Mixing System | In/Out bunker | 420L/250L | Mixer will mixingvarious raw materials to mixed, that to be a mixture or appropriate consistency machine.
|
|
Productivity | 5-6m3/h | ||||
Mixer motor | 11kw | ||||
Dimension | 1200-1500 | ||||
Total weight | 100kgs | ||||
