Home > Products > Semi-Automatic Block Making Machine > QT4-40 Middle Size Concrete Hydraulic Block Machineblock diagram lathe machine
QT4-40 Middle Size Concrete Hydraulic Block Machineblock diagram lathe machine
- Xiamen China
- T/T
You May Like
-
HOT IN 2012 HYM3-25 Semi-automtic block making machine eps block machine
-
HY-QT3-25 Semi-automatic block making machine beton blocks machines
-
HYM-4-40 manual block making machine machine of block machine offers
-
NEW! QT4-40 The most potential used concrete block making machine solid block machine price
-
2010-2013 Most popular hollow bricks made of concrete block making machine price in india
-
(HYM3-25) fly ash brick making machinery Semi-automatic block making machine cement block machine
Product Details
| Condition | New | Type | Hollow Block Making Machine | |
| Brick Raw Material | Cement | Processing | Brick Production Line | |
| Method | Hydraulic Pressure | Automatic | Yes | |
| Capacity | 20sets/month | Place of Origin | Fujian, China | |
| Brand Name | HYM | Model Number | QT4-40 | |
| Voltage | 380V | Power | 15.5kw | |
| Dimension(L*W*H) | 1500*800*2200mm | Certification | iso9001:2000 | |
| After-sales Service Provided | Overseas service center available |
Product Description
1.Brick shaping machine
2.block diagram lathe machine
3.hydraform block machine
ncrete block making machine
ISO9001:2000
1,Main technical Specifications:
1. It consists of mechanic, electricity and hydraulic in one machine, and it runs automatically in circulation each procedure is interlocked, and the pressure is automatically assigned.
2. Easy to change mechanical action according to different raw materials.
3. Fault self-diagnosis, comport for remote control guarantees technical support and maintenance.
Raw materials :crushed stone ,sand, cement, etc; many type of industrial waste, like, lime, fly ash, slag, coal gangue, gravel, perlite, ect. .
multiple uses, it can produce all type of standard building blocks by changing mould.
1,Multi-holes block and hollow block .
2,Ceram site heat preservation block.
3,Composite heat preservation concrete block
The above production come with good heat preservation performance, and it meets the new national energy conservation policy.
Cycle Time | 25-30(s) | Total Power | 15.5(kw) |
Vibration Type | moto vibration | Vibration Frequency | 3800-4500(Times/sub) |
Machine Dimension | 1600×800×2200(mm) | Pallet Size | 850×560×20(mm) |
Vibration Force | 25KN | Gross Weight | 1800(kg) |
Production/Mould | 4pcs/m (390x190x190mm) 12 pcs/m (240x115x90mm) 24 pcs/m (240x115x53mm) 15 pcs/m (200x100x60mm) | Productions/8hours | 960-1500pcs(390x190x190mm) 2800-4600pcs(240x115x90mm) 6200-7000pcs(240x115x53mm) 3600--5700pcs (200x100x60mm) |
