Cheap H beam Production Assembly Lines Made in China
- Shanghai
- T/T Credit Card PayPal
You May Like
-
Cheap H type Heavy Vertical Assembly Machine
-
Low cost H beam Steel Structure Fabrication Machine
-
H beam Build Up Line Assembly Machine
-
Low Cost Beam Auto Assembly Machine
-
YQ Gantry type CNC Cutting Machine with Flame & Plasma Cutting Torch
-
YQ CNC Plasma and Flame Cutting Machine with ISO & SGS & CE CNC
Product Details
| Place of Origin | Jiangsu, China | Brand Name | YQ(YaoQiang) | |
| Model Number | Z15 / Z18 / Z20 | Condition | New | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
I/H beam Automatic assembly Machine
H-beam automatic assembly machine is a kind of H-beam full-automatic assembly equipment based on extensive market. Positioning of flange and web is adopted with hydraulic transmission, both sides clamped and aligned mechanically, ensuring precise positioning of web and flange of different width within specified range. Automatic alignment is accurate,no need to adjust every time.
Main technical specifications:
1,The main structure: Main frame,upper gate frame,synchronous clamping and centralizing system of web and flange, main transmission motor reducer;
2.Applicable workpiece specifications: Web height:200-2000mm,Flange width:200-800mm,Length:4000-15000mm;
3,Clamping system:Web and flange automatic clamping;
4,Inlet table roller system: Active and passive table roller: 2.6m*3sets, tension rod: 3 sets;
5,Outlet table roller system: Active and passive table roller: 2.6m*3sets;
6,Hydraulic system: Oil bump station,high pressure rubber pipe,and hydraulic cylinder.With pressure keep and Time delay function;
7,Electric control system: Electric cabinet,AC frequency converter and etc;
8,Host drive control: Ac motor + Cycloidal reducer;
9,Power: AC 380V frequency 50Hz 3 phase;
10,Adopt imported technology of frequency converter to AC frequency convertor centralizes and locates the web and flange,and realize automatic working;
11,CO2 gas shield welding or manual welding are optional for user.
Model | Z15 | Z18 | Z20 |
web height mm | 200-1500 | 200-1800 | 200-2000 |
web thickness mm | 6-50 | 6-50 | 6-50 |
web length mm | 4000-15000 | 4000-15000 | 4000-15000 |
flange width mm | 200-800 | 200-800 | 200-800 |
flange thickness mm | 6-80 | 6-80 | 6-80 |
assembly speed mm/min | 500-6000 | 500-6000 | 500-6000 |
feeding table roller mm | 2600×2 | 2600×2 | 2600×2 |
output table roller mm | 2600×2 | 2600×2 | 2600×2 |
centralized way | hydraulic link mechanism clamp,centralize and weld in the middle automaticly | ||
speed control | imported AC frequency adjustor stepless adjust | ||
input volumn | 16KVA exclude wellding power | ||
welding system | 2 sets of CO2 protecting welding machine | ||
H beam Automatic Assembly Machine Images Show:
Our Service--We Cherish Every Order From Every Customer
Punctual delivery time:
•We put your order into our tight production schedule, ensure your punctual delivery time.
•Production / inspection report before your order packed.
•Shipping notice/ insurance to you as soon as your order is shipped.
Pre-sales service:
•We value every inquiry sent to us, ensure quick competitive offer within 12 hours.
•We cooperate with customer to design and develop the new products. Provide all necessary document.
•We are a sales team, with all technical support from engineer team.
After sales service:
•We respect your feed back after receive the goods.
•We provide 12-24 months warranty after goods arrive.
•We promise all spare parts available in lifetime use.
•We lorge your complain within 48 hours.
Trade Assurance:
Packaging & Delivery:
Packaging Details: Standard export package
Delivery Details: Within 15 days after received deposit
Company Show:
Company Honor:
Transaction Process:
Sales Network:
FAQ:
1. Are you factory or foreign trade company?
We have our own factory, We are industry and trade integration.
2. Where is your factory located? How can I visit there?
Our factory is located in Dongtai City, Jiangsu Province, one hour train from Shanghai.All our clients, from home or abroad, are warmly welcome to visit us!
3. What's the quality of your products?
We are very focused on the quality of the products, good quality products can bring us more customers, so, All spare parts of this machine come with best brand and best quality, after completing the installation we will test the machine for 48 hours, also we can provide the machine's working video before shipping.
4. What shall we do if don't know how to operate your machine after bought from you?
We have detailed installation and operating instructions attached, also comes with video, it is very simple. We have telephone and email support at 24 hours a day.
5. What to do if the machine has a problem?
24 hours timely response of mail and phone calls. If the parts broken belong to non-artificial factors within 12 months, we offer free replacement. If beyond 12 months, customers should bear the freight back and forth and accessories cost.
6. What other things also need after we bought your machines?
(1) With flame cutting: you just need to access to oxygen and fuel gas. (2) With plasma cutting: need plasma power source and air compressor. You can match plasma power supply by yourself, or buy together with the cutter from us, it's optional. If you buy from us, we will connect the wires of plasma power source and CNC cutting machine together, then more conveniently to use.
7. How can I know more about the machine?
We are honored to send you some pictures and vedio about our machine. And we welcome every customer visit our factory.
8. How does your factory do regarding quality control?
Quality is priority. Factory director always attach great importance to quality controlling from the very beginning to the very end. Our factory has gained ZDHY, ISO9001 authentication.
9. What are your payment terms?
We support T/T, L/C, Western Union and so on. Other ways can also be received after we both sides discussion and agreement. Any other questions contact us directly!
