wood machinery CE norm double end tenoner
- 15 Set / Sets per Month
- ShunDe
- T/T D/P D/A Credit Card
You May Like
Product Details
| Condition | New | Type | Double Side Planer | |
| Place of Origin | Guangdong, China | Brand Name | FirMy | |
| Model Number | FMD8625 |
Product Description
Specifications
Double End TenonerPrecise and work stably
Inverter feed 30 m/min(Standard)
Max to be 45 m/min
Double End Tenoner
Model | Working size | OD for tools | ID for tools | ||||||||
Length | Thickness | Scoring saw | Cut-off saw | Milling cutters | Scoring saw | Cut-off saw | Milling cutters | ||||
FMD8620 | 250~2000 | 6~80 | Ø 160 | Ø 300 | Ø 125~ Ø 180 | Ø25.4 | Ø 35 | Ø40 | |||
FMD8625 | 250~2500 | ||||||||||
FMD8630 | 250~3000 | ||||||||||
| |||||||||||
Motor power | Feeding speed | Weight( Tons approx) | Size (L×W×H) mm | ||||||||
Scoring saw | Cut-off saw | Milling cutter | |||||||||
2.2KW | 4KW | 5.5KW | 5~25m/min | 5.0T | 3880×3300×1800 | ||||||
5.3T | 4380×3300×1800 | ||||||||||
5.6T | 4880×3300×1800 | ||||||||||
Options:
1. Lengthen convey belt extend machine cover 1100mm.
2. Adopted Digital controlled system, servo motor for feeding and widen.
3. Jumping device for scoring saw
4. Electrical centralized lubricant system.
5. Inverter motor for cut-off saw, rotation speed can up to 4500r/min.
6. CE norm
Advantage
1. Electrical movement for the pressure belt with the pneumatic locked and controlled by digital positioner.
2. Machine base is processed by big CNC machine, over 1300mm width. Two high precision linear orbits are assembled and with steel dusty proof to protect.
3. All the tools with protection cover. Under the saws, there has over 400mm width 90° dust collector, easy to clean.
4. With the special location locked system and the little fence against the work pieces just with the surface, so it will not leave pressed mark in the work pieces.
5. High speed spindle (8000r/min)
6. High precision lightweight convey belt is assembled with bearings. High feeding speed and less noise, it is suitable for high speed processing
