High Technology 1 Ton Steam Boiler

4.Features Of 1 ton steam boiler

l         Special big combustor design increases heating area of furnace and decreases the boiler’s volume, lower the emission of NO_X

l         With ripple furnace to ensure higher safety.

l         With threaded smoke tube to faster heat conducting and improve the heat efficiency.

l         The front and back smoke tube box are sealed with many levels to guarantee no smoke leaking.

l         The boiler control system can lastingly work under the high temperature and high humidity environment.

l         Bigger steam room and better steam quality.

l         Multiple interlock protection like water level, steam pressure and gas pressure etc..

l         The boiler is covered with efficient insulation material to avoid heat loss.

l         Boiler production strictly follow China National norms and standards. All pressure accessories are made of best quality boiler steel.

l         Every boiler will be checked and tested strictly before delivery, including water pressure test and X ray test.

l         Choose best suitable burners to make sure boiler working safty and reaching rated output.

l         All accessories like burners, water pump, water level controller, valve instruments etc. are famous brand products.

l         Man hole and hand hole are designed for easy maintaining.

5. Installation Diagram of 1 ton steam boiler
