High Quality EPS Batch Foam Machinery With CE
- shanghai/ningbo
 - T/T

You May Like
Product Details
| Condition | New | Product Type | Other, packaging, construction | |
| Place of Origin | Zhejiang, China | Brand Name | VST | |
| Model Number | PSJ110,Batch foam machinery | Voltage | 380V | |
| Power(W) | 16.13KW | Dimension(L*W*H) | 5600*3800*4530(mm) | |
| Weight | 3500kg | Certification | CE, Other, CE, IOS9001 | |
| Warranty | 12 month | After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Specifications
Batch foam machinery:1.PLC and touch screen
2.Full automatic
3,Warranty: 1YEAR
1.Pictures of Batch foam machinery
2.Technical Data of Product
| Item | PSJ110 | PSJ130 | PSJ160 | |
| Expansion chamber | Diameter | Φ1100mm | Φ1300mm | Φ1600mm |
| Volume | 1.4m3 | 2.4m3 | 5.4m3 | |
| Usable volume | 0.9m3 | 1.6m3 | 4.5m3 | |
| Steam | entry | DN50 | DN65 | DN100 |
| consumption | 6-9kg/cycle | 10-12kg/cycle | 18-20kg/cycle | |
| pressure | 0.6-0.8Mpa | 0.6-0.8Mpa | 0.6-0.8Mpa | |
| Compressed Air | entry | DN25 | DN40 | DN40 |
| consumption | 0.5-0.6m3/cycle | 0.7-0.9m3/cycle | 0.5-0.8m3/cycle | |
| pressure | 0.6-0.8Mpa | 0.6-0.8Mpa | 0.6-0.8Mpa | |
| Drainage | Drainage port | DN80 | DN100 | DN150 |
| condensate | DN80 | DN100 | DN50 | |
| Throughput | 12g/l 530g/h | 12g/l 1500g/h | ||
| 12g/l 240g/h | 15g/l 670g/h | 15g/l 2000g/h | ||
| 15g/l 320g/h | 20g/l 920g/h | 18g/l 2600g/h | ||
| 20g/l 430g/h | 30g/l 1220g/h | 25g/l 3100g/h | ||
| 30g/l 600g/h | second expansion | second expansion | ||
| 8g/l 250kg/h | 8g/l 800kg/h | |||
| 10g/l 300kg/h | 10g/l 1000kg/h | |||
| Material converying pipe | Φ150mm | Φ150mm | Φ250mm | |
| Power | 16.13kw | 20.3kw | 38.45kw | |
| Density | 12-30g/l | 12-30g/l | 12-30g/l | |
| Density tolerance | ±3% | ±3% | ±3% | |
| Overall dimension | L*W*H | 5600*3800*4530(mm) | 7380*3000*4500(mm) | 11000*2840*6050(mm) |
| Weight | 3500kg | 4200kg | 8000kg | |
| Room | 5000mm | 5500mm | 7000mm |
3.Features of Product
1.Steam system:
Use precise pressure reducing valve and PID(proportional valve system) to keep constant steam.
2.Pressure control:
Batch foam machinery‘s pressure sensor works with multi-valves venting system, ensuring stable pressu Pre-expanded polystyrene re inside expansion chamber.
3.Temperature control:
Adopts temperature sensor and compressed air proportional valve to keep accurate expansion temperature, suitable for high density expansion.
4.Material level control:
Use vibration sensor to control material level.
5.Material filling system:
With batch controller and weighing scale to ensure same input weight every batch.
6.Electrical control:
PLC and touch screen, electronic parts, valves etc. are all of famous brand at home and abroad
4.Application of Product
5.More Products for You to Choose
MOQ  | 1 Set  |
Payment Method  | L/C, T/T  |
Port  | Shanghai/Ningbo  |
Delivery  | 30 days after received deposit or LC  |
Supplier Capacity  | 20 units per month  |
Packing  | standard exporting package .  |
