YC,YL,YY,JY Single Phase Two Speed Electric Motor

FOB Price

Negotiable / Piece

1 Piece(Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Brand Name	FOLK or OEM	Model Number	YL series
Type	Asynchronous Motor	Frequency	50Hz, 60Hz
Output Power	0.25kw to 7.5kw	Protect Feature	Totally Enclosed
Phase	Single-phase	Certification	CCC, CE, ROHS, Other, CCC, CE, ROHS, ISO9001
AC Voltage	208-230 / 240 V	Place of Origin	Zhejiang, China
Efficiency	IE 1

Description of product

YL Series Single-phase Induction Capacitor Motor

1,Frame Size: H56-132;
2,Power: 0.25-7.5Kw
3,Voltage:110-240V

4, Rated Frequency: 50 Hz / 60 Hz;

5, Poles: 2 / 4

6, Speed: 1450 -2980 r/min

7, Ambient Temperature: -15°C-40°C

8, Model of CONEECTION: Y-Connection for 3 KW motor or less while Delta-Connection for 4 KW motor or more;

9, Mounting: B3; B35; B34; B14; B5; V1;

10, Current: 1.5-30 A (AC);

11, Duty: continuous (S1);

12, Insulation Class: B / F;

13, Protection Class: IP44 / IP54;

14, Cooling Method: ICO 141 Standards;

15, Altitude: No more than 1,000 meters above sea level;

16, Packing: 1pc in a Strong carton several cartons on a Pallet or Plywood case.
