Home > Products > API sucker rod coupling > China Manufacturer! 3/4" Class T full size sucker rod coupling
China Manufacturer! 3/4" Class T full size sucker rod coupling
- Tianjin QingDao Shanghai
- T/T D/P D/A Credit Card
You May Like
Product Details
| Material | Other, AISI5140 | Technics | Other, hot rolling | |
| Type | Coupling | Place of Origin | Henan, China | |
| Model Number | 3/4" Class T | Brand Name | BLT | |
| Connection | Female | Shape | Equal | |
| Head Code | Other, Round |
Product Description
Specifications
3/4" Class T full size sucker rod coupling2.Std Rfc:API 11B
3.Surface treatment:whole phosphating
4.Advantage:anticorrosion
3/4" Class T full size sucker rod coupling
Detailed Descriptions
We our company is a manufacturer. We specialized in couplings and hydraulic tongs. The couplings include different types of couplings, such as sucker rod coupling, tubing and casing coupling, and so on. There are different sizes of different types of couplings. The info of the following table is about sucker rod couplings.
Technical Parameters
Sucker rod coupling | 3/4” | 7/8” | 1” |
Grade | 19-T | 22-T | 25-T |
O.D(mm) | 41.05~41.43 | 45.75~46.13 | 55.35~55.73 |
Minimum lengh(mm) | 101.6~103.17 | 101.6~103.17 | 101.6~103.17 |
Material | AISI 5140 | AISI 5140 | AISI 5140 |
Hardness | 56-62HRA | 56-62HRA | 12-23HRA |
Threads per inch(Piece/inch) | 10 | 10 | 10 |
Weight (kg) | 0.65 | 0.8 | 1.15 |
Standard reference | API 11B | API 11B | API 11B |
Feature | Anticorrossion, durable use | ||
Packing | Exported by case,wooden case or wooden pallet | ||
Delivery time | 15 working days after your order confirmation | ||
Surface treatment | Phosphating or per the clients request | ||
Contact Us
- Puyang Bao Litong Petroleum Machinery Co., Ltd.
- Contact nameDiangong Shi Chat Now
- Phone86-0393-8910958
- Addressyellow river road west jinger road west, Puyang, Henan
