20feet and 40feet Iso Tank Container Made in China
- Qingdao
- T/T Credit Card PayPal
You May Like
Product Details
| Condition | New | Capacity | 10000L--50000L | |
| Place of Origin | Shandong, China | Brand Name | Luqiang | |
| Model Number | LQR201 | Dimension(L*W*H) | Customerized | |
| Weight | Vary | Certification | ISO9001:2008, BV | |
| Warranty | 5 Years | After-sales Service Provided | No overseas service provided |
Product Description
| NO. | CONTAINER DIMENTIONS | OIL TANK CAPACITY | OIL TANK DIMENSIONS(mm) | OIL TANK LAYERS | chamber/ oil type | THICKNESS |
| 1· | 20feet | 15000L | φ2200*4200 | single wall | single chamber | 5mm |
| double chambers | 5mm | |||||
| φ2270*4270 | double wall | single chamber | inside6,outside5 | |||
| double chambers | inside6,outside5 | |||||
| 2· | 40feet | 30000L | φ2200*8300 | single wall | single chamber | 5mm |
| double chambers | 5mm | |||||
| φ2270*8370 | double wall | single chamber | inside6,outside5 | |||
| double chambers | inside6,outside5 | |||||
| 3. The container including: | ||||||
Note: Customized to suit customer requirements .
Standard Specification
Model | Total volume (Liter) | Container inner dimension(mm) | Inside tank dimension(mm) | Total weight(ton) |
20feet mobile fuel station | 10,000 | 5895x2350x2390 | 4500x1500x1500 | 4.23 |
15000 | 5895x2350x2390 | 4300x2200x2200 | 4.55 | |
16000 | 5895x2350x2390 | 4500x2200x2200 | 4.74 | |
20,000 | 5895x2350x2390 | 4500x2150x2150 | 4.93 | |
40feet mobile fuel station | 30,000 | 12029x2350x2390 | 6800x2250x2000 | 6.95 |
36,000 | 12029x2350x2390 | 8150x2250x2000 | 7.25 | |
40,000 | 12029x2350x2390 | 8800x2280x2000 | 7.75 | |
50,000 | 12029x2350x2697 | 10500x2250x2150 | 8.39 | |
55000 | 12029x2350x2697 | 10500x2280x2300 | 9.35 |
(1.) Accessories details included:
1. 6 mm and 4mm steel inner tank (double wall tank)
2. Two fuel dispensers, oil guns, rotary joint and oil pipes.
3. Bottom loading system:
fast unloading connector with cover
detachable filter
Overflow proof valve
Drainage system
4. Support and tank anti-skid system
5. Emergency ventilation system (each compartment)
6. Vacuum pressure valve and the pipeline
7. Emergency cut-off valve
8. Siphon preventing valve
9. Adjustable pressure pump
10. Oil cavity
11. Fuel dispenser installed base
12. Explosion-proof hose and wiring
13. Spill-proof alarm
14. Tank manhole covers
15. The lifting rings (according to request)
16. Tank high solid base coating
17. Tank high quality finishing paint
18. Tank customized logos or labels
19. Liquid inlets and outlets
20.Leakage indicator
21.Control panel
22.Thermal insulating materials
23.Sight glass
24.Thermometer
25. CIP universal cleaning device
26.Static pressure transmitte
27. Liquid level meter
