Home > Products > Aluminum Outdoor Series > High Quality 35w Waterproof Plastic With Good Performance
High Quality 35w Waterproof Plastic With Good Performance
US$ 9.7 - 10.4
/ Piece
24 Pieces(Min. Order)
- Shanghai or Shenzhen
- T/T Credit Card
You May Like
-
High Quality Waterproof 220v to 12v Led Power Supply Driver Supply
-
Plastic Housing Waterproof Dc12v Led Driver Power Supply
-
High Power Waterproof 24v dc Constant Voltage Led Driver Supply
-
High Efficiency Waterproof 24v Led Driver Constant Voltage Supply
-
High Compatility 600w Waterproof Switching Power Supply 220v Power Supply
-
China Manufactuer Waterproof 250w 220v 12v Hot Sale
Product Details
| Place of Origin | Hunan, China | Brand Name | XINWEIDA | |
| Model Number | HXF-400A-12/24 | Output Power | Other, 400W | |
| Output Type | Single | Input Voltage | Other, 180~240V | |
| Output Voltage | 12V | Output Frequency | 50/60Hz | |
| Output Current | 33A |
Product Description
High quality 35w waterproof plastic with good performance
High quality 35w waterproof plastic with good performance
Product Advantages
- Dual transistor forward circuit plan, more stable, more reliable
- Built-in EMI filter circuit, no interference, no blink or slash phenomenon
- Short circuit, over load & over current protection, safe and secure
- Unique copper slice built-in transformer technology, low temperature & good EMC performance
- The output inductance using alsifer sendust material (Fe-Si-Al Alloy Core), high output efficiency
- Sufficient power output, 100% full load burning test
Specification | Size(mm) | Working Temperature | Efficiency(>) | AC Input Voltage Range | AC Inrush Current | Output | Power | Protection | Protection Mode |
| HXS-30-12 | 270*29*21 | -20~40C | >82% | 100~240V | 100Amp max | 12V/2.5A | 30W | OLP,SCP | Hiccup Mode |
| HXS-60-12 | 172*67*37 | -20~40C | >82% | 100~240V | 100Amp max | 12V/5A | 60W | OLP,SCP | Hiccup Mode |
| HXS-100-12 | 227*67*37 | -20~40C | >82% | 100~240V | 100Amp max | 12V/8.33A | 100W | OLP,SCP | Hiccup Mode |
| KRF-200-12/24 | 207*122.5*66.5 | -20~40C | >82% | 180~240V | 100Amp max | 12V/16.7A | 200W | OLP,SCP,OVP | Hiccup & deadlock Mode |
| KRF-350-5 | 207*122.5*66.5 | -20~40C | >77% | 180~240V | 100Amp max | 5V/70A | 350W | OLP,SCP,OVP | Hiccup & deadlock Mode |
| KRF-150-12 | 195*114*57 | -20~40C | >82% | 180~240V | 100Amp max | 12V/12.5A | 150W | OLP,SCP | Hiccup Mode |
| KRF-400-12 | 243*143*66 | -20~40C | >82% | 180~240V | 100Amp max | 12V/33.33A | 400W | OLP,SCP,OVP | Hiccup & deadlock Mode |
| HXF-200A-5 | 213*94.5*49.5 | -20~40C | >77% | 180~240V | 100Amp max | 5V/40A | 200W | OLP,SCP | Hiccup Mode |
| HXF-300A-5 | 218*94.5*49.5 | -20~40C | >77% | 200~240V | 100Amp max | 5V/60A | 300W | OLP,SCP,OVP | Hiccup & deadlock Mode |
| HXF-25A-12 | 148*86.5*42 | -20~40C | >82% | 180~240V | 100Amp max | 12V/2.1A | 25W | OLP,SCP | Hiccup Mode |
| HXF-60A-12 | 118*65*37 | -20~40C | >82% | 180~240V | 100Amp max | 12V/5A | 60W | OLP,SCP | Hiccup Mode |
| HXF-150A-12 | 209*74*42 | -20~40C | >82% | 180~240V | 100Amp max | 12V/12.5A | 150W | OLP,SCP | Hiccup Mode |
| HXF-250A-12 | 213*94.5*49.5 | -20~40C | >82% | 180~240V | 100Amp max | 12V/20.8A | 250W | OLP,SCP | Hiccup Mode |
| HXF-400A-12/24 | 218*117*49.5 | -20~40C | >82% | 180~240V | 100Amp max | 12V-33A | 400W | OLP,SCP | Hiccup Mode |
| Feature | Short circuit,overload,over-current protection | |
| Model Link | Indoor 5V Series | HX-200-5 HX-200E-5 HX-200F-5 HX-300-5 HX-400-5 | |
| Indoor 12V Series | HX-75-12KC HX-350KC HX-150-12KC HX-200-12KC HX-250-12KC HX-400-12KC HX-25-12 HX-60-12 HX-100-12 HX-120-12 HX-150-12 HX-200A-12 HX-250A-12 HX-400C-12 HX-500-12 KR-15-12 KR-350-12 | ||
| Indoor 24V Series | HX-60-24 HX-100-24 HX-400C-24 HX-500-24 KR-25-24 | ||
| Outdoor Series | HXS-30-12 HXS-60-12 HXS-100-12 KRF-200 KRF-350-5 KRF-150-12 KRF-400-12 | ||
| AC AD Adapter Series | HX08-1201(219) HX08-1201(319) HX08-1202(218H) HX08-1202(2000) HX08-1203(301) HX08-1205(608) HX08-1206-(608) | ||
