Superior Modern Acp Panel High Quality Sheet Alucobond

FOB Price

US$ 310,000 - 580,000 / Set

1 Set(Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Zhejiang, China		Brand Name	OEM
Model Number	YS-04		After-sales Service Provided	Engineers available to service machinery overseas

Material property
Raw material	Aluminium or Aluminium Alloy coil
Width	910~1,600mm
Thickness	0.10~0.50mm
Coil inner diameter	φ150/405mm
Coil exterior diameter	φ1,200mm(max)
Coil weight	3,000kg(max)
Assistant material
Specification	Fluorin Carbon	Polyester Dope	Acrylic acid dope
Coating viscidity (4 cups)	60~120	60~110	55~110
Thickness of the dry film μm	15~25	15~25	15~20
Dry temperature (°C)	249~254	210~224	183~210
Line speed M/min	8~15	10~20	10~25
Heating
Heating time	220°C/60mins
Heating method	Stainless steel resistance fim heating unit
	S.C.R. silicon controlled adjustable electricity output
	Temperature controller: PID automatic calculation procedure temperature-controller
Electricity
Main power	3φ-380V-50HZ
Electric power	484.2KW(heating)+ 70HP(motor)
Practical power	280kw
Pressure of condensed air
Pressure	5~6kgf/cm2
Air quantity	0.2~0.8M3/min
Others
Water quantity	Industry water
Water pressure	0.5~2.0kg/cm2
Water quantity	0.1~0.5M3/hour
Equipment speed	0~30M/min
Equipment size	52,000L×4,000W×5,200H mm
Equipment weight	96,000kg(approximately)
