Home > Products > New Products > Industrial Buildings and Blasting Drill Machine

Industrial Buildings and Blasting Drill Machine

FOB Price

US$ 1 - 10 / Set

1 Set(Min. Order)

Port shanghai
Payment TermsT/T

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition	New	Type	Core Drilling Rig
Place of Origin	Chongqing, China	Brand Name	GOLD
Model Number	GX-1TD	Usage	Coal

Product Description

APPLICATIONS:

Geological drilling for railroad, highway, bridge tunnel, power station foundation, civil and industrial buildings and blasting hole etc.

2. FEATURES:

Spindle type, mechanical transmission, hydraulic feeding, and steel skid frame mounted.
Hydraulic retracting lets drill body away from the drill hole, in order to hoist or lower the drilling tools.
Hydraulic chuck, labor saving.
Advanced design, multi-function, compact structure, lightweight, good detachability, easy to operate.
Large-powered, reasonable range of speeds, large torque, suitable for many drilling methods.
According to user's requirements the drilling machine can be equipped with mudpump, a variety kinds of drilling tools, A-derrick etc, for client choice.

Technical Specifications

final hole dia (mm)		150;130;110;91;75
drilling capacity (m)		30;50;70;100;150
angle rangle		0-90°
spindle speeds (r/min)		90;191;360;600
max torque (Nm)		1000
Max pull force (KN)		27
spindle stroke (mm)		450
max hoisting force with single line (KN)		14.7
Oil pump		CB32
Power unit	diesel engine	S1100A 2200r/min 11KW
	electric motor	Y160M-4 1460r/min 11KW
Weight (Excluding power)(kg)		500
overal dim(L×W×H)(mm)		1560×620×1205

CHONGQING GOLD MECHANICAL & ELECTRICAL EQUIPMENT CO.,LTD

Established in 2009,Gold is a high -tech enterprise specializing in design,manufacture and sale of geological instrument.

Gold's products are manufactured stricity in accordance with industrial standard and have passed through quality and technical standard evaluation as well as quality inspection. In 2010,Gold passed through ISO9001 International Quality System Certification.In July 2010,Gold obtained provincial certification of high-tech enterprise,becoming an excellent supplier with outstanding product quality in China.

Gold's Products Spread All Over The Word

Provide Professional Technical Training

Excellent Team And Best After Sales Service

We are ready to provide perfect service for you !
