50M 80M 100M Water Well Drilling Machine and Core Drilling Machine
- Qingdao
- T/T Credit Card
You May Like
-
130m Underground Deep Water Well Drill Rigs and Drilling Equipment Price
-
100-600M Water Boring Machine and Water Well Drilling Rig Price
-
100m-600m Well Boring Machine and Machines to Dig Wells
-
Diamond Core Drill Rig and Water Drilling Rigs 100-600M
-
Concrete Core Drilling Machine and Water Well Drilling Machine for Sale
-
Optional Depth 100m,250m,600m Ground Water Well Drilling Rigs and and Ground Hole Drilling Machine for Good Sale
Product Details
| Condition | New | Type | Core Drilling Rig | |
| Power Type | Diesel | Place of Origin | Chongqing, China | |
| Brand Name | God | Model Number | 130 | |
| Usage | Ore | Dimension(L*W*H) | 2.5*1*1.3 M | |
| Weight | 560kg | Certification | ISO9001 | |
| Warranty | 1 year |
Product Description
Water Well Drilling Machine and Core Drilling Machine
I-- Applications:
High efficiency small portable hydraulic core drilling rig is applicable for high-way and building construction foundation,general survey, geophysical exploration and so on. The portable hydraulic core drilling rig has wide usage, the portable hydraulic core drilling rig is also suitable for different rock hardness.
II-- Features:
1. Keeping bracket is installed on the hoist to form a double wheel support structure, able to withstand strong blow.
2. Vertical box are fixed by four groups of bearings to ensure that the rotary machine has sufficient rigidity to overcome gravel layer and other complex geological conditions.
3. The machine is equipped with national patent technology-taper clutch, with charactristics of strong transimission torque, easy operation and free maintenance.
4. 53x59 drilling rod adopted, high rigidity and strong delivery torque.
III-- Specifications:
Unity machine parameter | |
Drilling depth | 130m |
Maximum open hole caliber | 260mm |
End hole caliber | 75mm |
Drill rod caliber | 50mm |
Drilling angle | 90~75 |
Drill weight (No include power) | 510 560kg |
Unity machine dimensions | 2.5×1×1.3 2.5×0.9×1.3m |
Spindle | |
spindle speed | 142,285,570r/min |
Spindle stroke | 450mm |
Hoist | |
Max.single line hoisting capacity | 960kg |
Single line lifting speed | 0.41,0.82,1.64m/s |
Tightrope caliber | 27m |
Mud pump | |
Type | Horizontal single urn twin-action |
Displacement | 95/77L/min |
Diesle engine | S1105model 18HP |
Electric motor | Y160M—4 11kw 1440r/min |
Maximum pressure | 1.2Mpa |
Work pressure | 0.7Mpa |
Water inlet caliber | 30mm |
Water to exit caliber | 25mm |
Triangle conveyer belt | B1575mm |
