LiFePO4 Battery for UPS with 12V Voltage and 60Ah Nominal Capacity

Specification:


Model: TB-12100F
Type LiFePO4 battery with PCM
Nominal voltage: 12.8V
Typical capacity 100Ah
Internal Impedance(1kHz AC) <60mΩ
Max Charge voltage N/A
Discharger cut-off voltage 9.2±0.05V
Max charge current 100A
Max continuous discharge current 100A
Max pulse discharge current 300A (2s)
Charging temperature 0°C~45°C
Discharging temperature -20°C~60°C
Storage temperature -20°C~45°C
About 2000 cycles to 80% with 100% DOD under 20 °C~25°C
Size(L*W*H) 327*172*216mm
Weight: approx.13.0kg
Application:Forklift, clean car, bus, solar and wind energy systems, attractions tour, hybrid vehicle and so on.
We can offer model: 12V 50Ah,80Ah,100Ah,125Ah,200Ah,300Ah,400Ah


Feature:
1.Long life, large capacity and good shock resistance
2.Low self-discharge and good discharge performance at low temperature
3.Strong charging acceptance and quick-charging capability
4.Strong over-discharge resistance and charge retention
5.Maintenance-free and no acid or water for maintenance in usage
6. Lighter weight smaller size
7.Most safe no explosion no fire

♦Warranty: 2-10 years

Depending on the different application and use of the environment.

♦How to get the quotation from us?

1.Please tell us the detailed application? what is the voltage and capacity?
2.Please tell us the continuous discharge current or motor power?
3.Please tell us the requirements of dimensions? (length*width*height)mm
4.Please tell us whether need charger? and how long charging time?

What Applications of our Lithium ion battery packs?

1. Emergency power supply, LED light & flashlight: headlamp, emergency light, solar flashlight, searchlight, lantern, bicycle light, bright flashlight, high-end lamp, military flashlight and so on.
2. Home appliance products: electric vacuum cleaner, eletric sweeper, water meter, gas meter, electrinc children toys, electric warm shoes, electric blancket, TV remote control (RC) and so forth.
3. Consumer applications, communicate & telephone equipment: MPS, tablet PC, laptop, Bluetooth earphone, power bank, portable DVD player, speaker, microphone, sound equipment, audio, digital camera and others
4. Outdoor sports products: camping light, mountain bike light, solar emergency light, self-defense flashlight and that .
5. Electronical tools & electric transportation vehicles: electric bike, electric car. e-scooter, electric motor and all that.
6. Solar lawm, remote control
7. Medical device
8. Backup power supply
9. Electrical and hobby
10. UPS, GPS

About Us

We specialized in LiFePO4 New energy vehicle power Battery, Lithium ion Battery Engine Start Battery, Backup Storage Battery for Communication base stations, solar & wind hybrid energy storage and household energy storage battery system solutions.

How to Maintain Lithium Battery

Lithium batteries are presently the most commonly used energy storage devices on electric bike, electric scooter, golf car, mobile phones, laptops, digital cameras and other electric devices. Learning how to maintain lithium batteries can not only prolong battery lifetime but also protect your device from potential damage.

1. Charge new batteries. It's not necessary to charge over 12 hours when first used. When a device powered by batteries is purchased, sellers will usually tell us the batteries must first be charged 12 hours before using. Actually, this is unnecessary. Unlike common Ni-CD or Ni-MH batteries, most lithium ion batteries are activated before leaving the factory. Due to their low self-discharge, it’s unnecessary to charge lithium ion batteries for such a long time when new. Lithium ion batteries are ready for use when the charger indicates so, and they will reach their best capacity after 3 or 5 cycles.

2. Use appropriate chargers. Many people take great care with their electronic gadgets, but often neglect the consequences of bad chargers on their lithium ion batteries. When choosing a charger, the original charger is the best choice. If that's unavailable, a high quality charger that has an overcharge protection function, or a brand name charger will do. A low quality battery charger can lead to shorter run times, premature battery failure, or even fire or explosion.

3. Avoid frequently over charging. Over charging with a low quality charger may let the battery's interior rise to a high temperature, which is bad for the lithium ion battery and charger. Thus, simply fully charging is good enough - overcharging will make your lithium battery into a little bomb if overcharge protection function is missing.

4. Avoid touching metal contacts. All batteries' contacts need to be kept clean for best performance. When carrying batteries around, do not let the contacts touch metal objects such as keys; this could cause a short circuit, damaging the battery or potentially resulting in a fire or an explosion.

5. Avoid using often in high or low temperature environments. Lithium ion batteries have optimal working and storage temperatures. If they're continually used in extreme temperature environments, this will negatively affect battery use time and useful cycles.

6. Avoid long periods without using or recharging. If batteries will be left unused for 3 months or more, partially recharge them (to around 30-70% of capacity, depending on planned storage time), then store the device to prevent battery damage. You may need to take the device out of storage and charge again after a few months.

What 10 Tips should be note when using Lithium ion battery?

Why choose us?

1. Quick response to clients' enquiries within 24hours.

2. Best solution provided by our experienced team and professional engineers.

3. More than 10 years experience in producing battery products for various application.

4. Value quality and long-term cooperation to reach win-win relationship.

5. Our Partneers thoughout 103 countries.

6. 365 companies used our products which are very satisfied.

What is the Payment method and Shipping?

1. Payment: T/T, Western Union, Paypal, Trade Assurance, L/C Webmoney and so on.
