High quality transparent Speaker Cable
- ningbo/shanghai
- T/T L/C D/P D/A Credit Card
You May Like
Product Details
| Packing | Other, 50m/100m | Type | Other, Speaker cable |
Product Description
Specifications
Speaker Cable1.OFC/CCA/tinned copper wires or CCS
2.Any AWG and Color are available
3.OEM&ODM projects
4.CE and ROHS
Speaker Cable
Speaker cable is used to make the electrical connection between loudspeakers and audio amplifiers. Modern speaker wire consists of two or more electrical conductors individually insulated by plastic such as PVC, PE or Teflon. The two wires are electrically identical, but are marked to identify the correct audio signalpolarity. High quality transparent Speaker Cable
Maximum wire lengths for two conductor copper wire
| Wire Size | 2 Ω load | 4 Ω load | 6 Ω load | 8 Ω load |
| 22AWG(0.326mm²) | 3ft(0.9m) | 6ft(1.8m) | 9ft(2.7m) | 12ft(3.6m) |
| 20AWG(0.518mm²) | 5ft(1.5m) | 10ft(3m) | 15ft(4.5m) | 20ft(6m) |
| 18AWG(0.823mm²) | 8ft(2.4m) | 16ft(4.9m) | 24ft(7.3m) | 32ft(9.7m) |
| 16AWG(1.31mm²) | 12ft(3.6m) | 24ft(7.3m) | 36ft(11m) | 48ft(15m) |
| 14AWG(2.08mm²) | 20ft(6.1m) | 40ft(12m) | 60ft(18m) | 80ft(24m) |
| 12AWG(3.31mm²) | 30ft(9.1m) | 60ft(18m) | 90ft(27m) | 120ft(36m) |
| 10AWG(5.26mm²) | 50ft(15m) | 100ft(30m) | 150ft(46m) | 200ft(61m) |
| Material ICAS% Conductivity | |
| Silver | 105% |
| Copper | 100% |
| Gold | 70% |
| Aluminum | 61% |
| Brass | 28% |
| Zinc | 27% |
| Nickel | 22% |
| Iron | 17% |
| Tin | 15% |
| Phosphor Bronze | 15% |
| Lead | 7% |
| Nickel Aluminum Bronze | 7% |
| Steel | 3 to 15% |
Any AWG and Color speaker cables are available.
For more details, please visit our website
ODM & OEM projects are welcome.
Welcome to inquire on us
Thank you very much!!
