2012 Hot Superlink Cat5e Network Cable
US$ 0.1 - 1
/ Kilometer
10 Kilometers(Min. Order)
- Shanghai or Ningbo
- T/T L/C D/P D/A
You May Like
Product Details
| Place of Origin | Zhejiang, China | Brand Name | SUPERLINK | |
| Model Number | network cable | Conductor Material | Other, CU/CCA | |
| Insulation Material | Other, PE/FPE | Jacket | Other, PE/PVC | |
| Number of Conductors | 8 | Application | For use in communication and signal control systems |
Product Description
Specifications
2012 hot superlink cat5e network cable(1)UL ETL CE ROhS
(2)Factory price
(3)Quick delivery
4))OEM is ok
2012 hot superlink cat5e network cable
cat5e
| 1) Construction | |||
| Center Conductor: | 24 AWG BC/CCA | ||
| Dielectric: | 0.90mm PE | ||
| Shield: | PET+Al Foil+0.5mmCCS | ||
| Jacket: | 5.8mm PVC | ||
| Nom. Thick: | 0.55mm | ||
| 2) Characteristics | |||
| Temperature Rating | -20°C to 60°C | ||
| Dielectric Breakdown: | 2500V | ||
| DC Resistance/Unbalance: | 28.6Ω/1000 Max/5% Max | ||
| Characteristics Impedance: | 100Ω | ||
| 3) Other Electric Performance | ||||
| Frequency | Attenuation | Return loss | Pair to Pair | |
| (MHz) | (dB/100m) | (dB/100m) | ||
| NEXT | ELFEXT | |||
| (dB/100m) | (dB/100m) | |||
| 0.77 | 1.8 | NA | 70 | 69 |
| 1 | 2 | 20 | 68.3 | 66.8 |
| 4 | 4 | 23 | 59.3 | 54.7 |
| 8 | 5.8 | 24.5 | 54.8 | 48.7 |
| 10 | 6.5 | 25 | 53.3 | 46.8 |
| 16 | 8.2 | 25 | 50.3 | 42.9 |
| 20 | 9.2 | 25 | 48.8 | 40.7 |
| 25 | 10.4 | 24.3 | 47.3 | 38.8 |
| 31.25 | 11.7 | 23.6 | 45.9 | 36.9 |
| 62.5 | 17 | 21.5 | 41.4 | 30.8 |
| 100 | 22 | 20.1 | 38.3 | 26.8 |
| 155 | 28.1 | 18.8 | 35.5 | 22.9 |
| 200 | 32.4 | 18 | 33.8 | 20.7 |
| 300 | 41 | 16.8 | 32.3 | 17.2 |
| 350 | 44.9 | 16.3 | 30.2 | 15.9 |
REMARK:
We will do the QC test for the goods before delivery .
We will do the QC test for the goods before delivery .
#Coaxial Cables:
1) RG series Coaxial Cable:Rg59, rg6, rg7, rg8, rg11, RG58, rg142, rg174,rg178, rg213, rg214, RG316,etc.
2) JIS series Coaxial Cable:1.5C-2V, 2.5C-2V, 3C-2V, 3C-2VR, 4C-2V, 5C-2V, 7C-2V, 10C-2V, 3D-2V, 5D-2V, 8D-2V, 10D-2V, etc.
3) Vatc series Coaxial Cable:17vatc, 19vatc, 21vatc, 25vatc, kx6a, kx8
4) TRUNK Cable:412, 500, 540
5) LMR SERIES:LMR200, LMR400, LMR600
#Network Cables:
2) JIS series Coaxial Cable:1.5C-2V, 2.5C-2V, 3C-2V, 3C-2VR, 4C-2V, 5C-2V, 7C-2V, 10C-2V, 3D-2V, 5D-2V, 8D-2V, 10D-2V, etc.
3) Vatc series Coaxial Cable:17vatc, 19vatc, 21vatc, 25vatc, kx6a, kx8
4) TRUNK Cable:412, 500, 540
5) LMR SERIES:LMR200, LMR400, LMR600
#Network Cables:
LAN Cable CAT3, LAN Cable CAT5, LAN Cable CAT5e, LAN Cable CAT6, LAN Cable CAT7 BT3002;
#POWER CABLE SPEAKER CABLE:
2*0.75MM 2*1.5MM 2*2.5MM 3*2MM
2*0.75MM 2*1.5MM 2*2.5MM 3*2MM
Combined Cable:Siamese Cables:RG59+2C
# Cable Materials
Al Wire, Al-mg Alloy Wire, Al Alloy wire;
Al Foil, Bonded Al Foil;
Copper Clad Alluminum wire,CCA, CCAM,CCAwire.
PVC film for cable packing
Al Wire, Al-mg Alloy Wire, Al Alloy wire;
Al Foil, Bonded Al Foil;
Copper Clad Alluminum wire,CCA, CCAM,CCAwire.
PVC film for cable packing
