Magnetic Parking Space Sensor Detector for Indoor/Outdoor/Street Smart Pakring Guidance System

  Magnetic Parking Space Sensor Detector for IndoorOutdoorStreet Smart Pakring Guidance System

ROSIM Vehicle detection System mainly include Wireless parking Space detection sensor ( WPSD-340S) and Wireless Data Collector ( WDC-400X).

Wireless Parking Space Detector is installed in each car park bay middle to detect its occupied or vacant status and how long it park on this bay. These data will be real time transmitted to platform software through Tcp/Ip network by Receiver WDC-400x, which supports Rs232 and Ethernet port. Wireless parking bay sensor is well used for outdoor/on-street smart parking guidance system and has a good reputation from clients.It is easily to integrate with the third party system for guidance, management, reporting and enforcement.

Wireless Parking Space Detector

Name: WPSD-340S

Brand: ROSIM

Original: China

Due to double detection technology with a sophisticated algorithm inside and and employment of LPLR low power-long range technology, WPSD achieves an extreme high detection accuracy, wide communication range, easy installing and cost-efficient parking lots occupancy data collection solution for indoor/outdoor parking management system.

 Data Collector

Name: WDC-400X
Brand: ROSIM
Original: China
Acts as a gateway between data server and all the wireless parking sensors to acquire the occupancy information of each parking spaces and relay to user system through its RS-232/485/Ethernet data interface.

Test and Configuration Tool

Name: Parkview
Brand: ROSIM
Original: China
It provides device configuration and operation status moitor functions as well as detection result display. A demo system or experiment of testing purposes can be easily achieved by Parkview software.



2)High accuracy: the ROSIM wireless Parking Space Detector featured with dual magnetic and optic detection technology. The combination of the two vehicle detection technology, as well as a sophisticated algorithm, greatly improves the accuracy and efficiency of the detection. accuracy>99%

3)Fast installation: it just needs about 2 minutes for installation of each WPSD because of  the adoption of pad installation;

4)work in all weather: Because the WPSD has strong characteristics of waterproof, snow defense, anti-press, anti-corrosion and strong anti-jamming capacity,it can normally work in all weather;

5)Average 3 years life span( replaceable);

6)Easy to maintain: Wireless parking space vehicle detector supports firmware updating over the air.

7) Low operation consuming: due to the ultra-low power design and battery supply solution, Wireless parking space vehicle detector (WPSD) ’s consumed power is very lower than any other detectors in the market. This appears more and more significantly to our environments;

2. Outdoor parking lots

3.On-street parking lots

For first contact, there is sample kit including every neccessary parts available for client test and demo.

The ordered products will be packed and delivered within 7 days

If still need any further information, welcome to visit us or contact the manager Rebecca:
