Home > Products > Boiler Tube > ASME SA335 P11 Alloy Steel Boiler Tube for High Temperature Services

ASME SA335 P11 Alloy Steel Boiler Tube for High Temperature Services

FOB Price

USD $1,200 - $1,500 / Ton

2 Tons(Min.Order)

Supply Ability 500 Ton / Tons per Month
Port shanghai
Payment TermsT/T

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Thickness	20, 40	Section Shape	Round
Outer Diameter	0.125 - 48 inch	Place of Origin	Jiangsu, China
Secondary Or Not	Non-secondary	Application	Boiler Pipe
Certification	Other	Surface Treatment	Other, Mill Lacquered,Galvanized,Bare
Alloy Or Not	Is Alloy

Product Description

Usage:

Boiler Tube, Construction of boilers, pipelines and equipments for high temperature and pressure services, and also suitable to be curved and flanged.

Detailed Images

Specification:

Quality Standard	ASME SA335
Steel Grade	P11
Outer Diameter	1/8″-48″
Wall Thickness Schedule	20, 30, 40, Standard (STD), Extra Heavy (XH), 80, 100, 120, 140, 160, XXH
Length	1.Fixed length within the random lengths range
	2.Tolerances on fixed lengths: +10/-0mm, for boiler tube and +50/-0mm for header pipe.
	3.Maximum length up to 24mtr
Surface Conditions	Mill Lacquered, Galvanized, Bare
End Finishes	Beveled, Square, Threaded, Threaded and Coupled, Grooved
Marking	Marking is done according to material standard or as per customer require
Marking	Tubes can be stenciled on ends or over entire length and die-stamped on one or both ends
Mill Test Certificates	Product are supplied with 3.1 test certificates, acc. To EN10204 Certificate acc. T 3.2 can be agreed at the time of ordering.

Grade	C	Si	Mn	P	S	Cr	Mo
P11	0.05-0.15	0.50-1.00	0.30-0.60	0.025 max	0.025 max	1.00-1.50	0.44-0.65

Packing & Delivery

Protection:

Unprotected

If required, the tubes can be delivered with plastic caps at both ends

Protection for sea transport on request

Delivery:

In hexagonal bundles tied with steel strip.

Bundles weight up to 5000kg.

Product Pictures
