The Best-selling Products Q245 Pipe Thread Lathe Price From Manufactory With High Quality

FOB Price

Negotiable / Set

1 Set(Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

SPECIFICATIONS

Outline size
L: 3300mm		W: 1450mm
H: 1600mm		Machine weight: 6000kg

Max.swing diameter on the bed 800mm		Diameter of pipe 50-245
Max.outside diameter of pipe 1000mm		Max. taper 1:32
Tails quill diameter 750mm
Spindle
Spindle bore 250		Level of spindle speed 12
Range of spindle speed 20-460r/min
Feed system
Vertical and horizontal feed species 32
Thus feed range
Processing metric thread number 21	Transverse 0.04-0.65mm
Inch thread processing number 26	Longitudinal0.1-1.46mm
Pitch processing metric thread 1-15mm
Inch thread processing pitch 1-14t.p.i
Saddle longitudinal moving speed 2.5m/min
The slide board box handwheel rotates a saddle longitudinal travel 0.20mm
Tool carrier
The spindle center line to the tool installation datum vertical distance 30mm	The surface of the knife section size 30×30mm
The cutter turntable rotation angle ±90°
The knife frame dial rotates every one stroke of knife 0.05mm
The lower sliding plate dial rotates one grid knife stroke 0.05mm
Spindle center line to the tool installation datum vertical distance 33mm
The tailstock
Top sleeve diameter 100mm	Top sleeve travel 250mm
Top sleevetaper Morse6	Tailstock lateral movement amount ±15mm
The top taper Morse6
The power part
Gear pump belt 1-A800		Rapid motor 2A0S5632 0.37KW2700r/min
The main motorbelt 4-B2240		Cooling pump JCB-22 0.125KW22L/min
Gear pump CB-B6 2.5Mpa 1450r/min		The main motor Y160M-4-B3 11KW 1460r/min

TaianHaishu Machinery Co.,Ltd.is specializing in the electromechanical integration products,

collection development,manufacturing,sales in the integration of high-tech enterprises.

The leading product is"HAISHU" brand CNC lathe,CNC milling machine,Machining

center,etc.We can supply the top quality products at the most favouriable price.

80% of our products is sold to aboard such as U.S.A.,Germany,Italy,Turkey,Greece,

India.Our products have enjoyde a high reprtation over there.

If we can coopetate with each other.I think we will build a very happy relationships

with each other!

Looking forward to your specific inquiries.
