HIigh quality and low price CRI-200 common rail injector test stand

HIigh quality and low price  CRI-200 common rail injector test stand

1. main function :

HIigh quality and low price CRI-200 common rail injector test stand     is Controlled by industrial computer in real time, Windows XP operating system. built common rail injector standard database; , optional touch screen or mouse actions.
HIigh quality and low price CRI-200 used diesel test bench can test BOSCHDENSODEPHISIEMNES, PIEZO and other common rail injectors.

CRI-200 CRI-200 common rail injector test stand   fuel injection quantity is measured by a measuring cup

2.Introduction:

1. The oil quantity is measured by sensor

2 Test data can be stored and print(optional).Built in standard database of common rail injector, and data can be Free upgraded for users can also be free to add data.

3.human interface, operate more convenient to use

4. The main frame includes aviation aluminum structure and cast iron operating platform

5.It has built-in electrical box and convert box. Short-circuit protection.

6. the maximum pressure is 200Mpa.

7.Automatic closed-loop control rail press accuracy displayed is ±0.1MPa.

8.Setting the parameters of injection curve,pull up current,dynamic current fixed time,keep and maintain time and so on.

 Checking of common rail injector open pressure and atomization quality.

9.Function of high-pressure cleaning of the injector.

10.Function of the ultrasonic cleaning

11.Testing of Start-up oil quantity.

12. Testing of the common rail injector sealing.

13. Testing of the common rail injector full –load operation.

14. Testing of the common rail injector idling conditions.

15.Testing of the common rail injector pre-injection conditions.

16.  Testing of the common rail injector opening conditions.

Taian Haishu Machinery co.,.ltd workshop

3. technical parameters

Transport and packaging
