High quality for big workpiece CW6150 mnaul lathe machine with CE from haishu
- Qingdao
- T/T Credit Card
You May Like
-
china engine lathe CW6140/CW6140B/CW6150/CW6150B common lathe machine Manufacturers
-
2015, new product CW6132 common lathe , common lathe machine form haishu
-
2015, new product CW6132 manual lathe , mnaul lathe machine form haishu
-
High quality for big workpiece CW6140/CW6140B/CW6150/CW6150B Common Lathe
-
lathe machines for sale Normal CNC or Not lathe machine parts and function
-
lathe machine parts and function/ Not cnc lathe machine
Product Details
| Condition | New | Type | Horizontal | |
| CNC or Not | Normal | Automatic Grade | Manual | |
| Max. Swing Diameter | 500mm | Place of Origin | Shandong, China | |
| Brand Name | Haishu | Model Number | CW6150 | |
| Voltage | 380v 50hz | Power(W) | 7.5KW | |
| Dimension(L*W*H) | 2500/2750/325 | Weight | 2000-4600KGS | |
| Certification | CE | After-sales Service Provided | Overseas third-party support available |
Product Description
contactor : Taian Haishu Machinery Co.,Ltd. Mobile phone :+86-13583808891 E-mail: hswj(@) Trademanager : cn1073767244 Skype: lucy001984
High quality for big workpiece CW6150 mnaul lathe machine with CE from haishu
I. Features
2.useThe lathe adopts the most mature and stable product technology and manufacturing process, with good rigidity, high precision, low noise, processing range, easy operation and maintenance, reasonable prices and other advantages. The machine is widely used, can be realized plate, shaft, thread, and other parts of the turning and drilling, reaming, reaming and other processing.
3.technical parameters
Item | CW6140 | CW6140B | CW6150 | CW6150B | |
CW6240 | CW6240B | CW6250 | CW6250B | ||
Maximum turning diameter over bed | Φ400mm | Φ500mm | |||
Maximum turning diameter over carriage | Φ220mm | Φ300mm | |||
Maximum Distance between centers | 750/1000/1500/2000/3000/4000/5000 mm | ||||
Maximum turning diameter over saddle | 630mm | 710mm | |||
Bed width | 390mm | 390mm | |||
Saddle width | 240mm | 240mm | |||
Up turret | 145mm | 145mm | |||
Horizontal slide travel | 320mm | 360mm | |||
Spindle head | C-6 | D8 | C-6 | D8 | |
Spindle diameter | Φ52mm | Φ82mm | Φ52mm | Φ82mm | |
Spindle bore taper | MT6 | Metric system 90 | MT6 | Metric system 90 | |
Spindle speed range | 24 9-1600rpm | ||||
Screw pitch | 12mm | ||||
Pitch threads | 54-1/4DP(45kinds ) | ||||
Module thread | 0.5-112mm(42 kinds ) | ||||
Inch thread range | 72-1/8tpi(48 kinds ) | ||||
Metric thread range | 0.5-224mm(48 kinds ) | ||||
Longitudinal feed range | 0.028-6.43mm/rev(93 kinds ) | ||||
Cross feeds range | 0.012-2.73mm/rev(93 kinds ) | ||||
Longitudinal rapid traverse rate | 4.5m/min | ||||
Horizontal rapid traverse rate | 1.9m/min | ||||
Tailstock taper | MT5 | ||||
Tailstock sleeve move | 150mm | ||||
Tailstock quill diameter | Φ75mm | ||||
Main motor power | 7.5kw | ||||
Cooling motor power | 90w 25L/min | ||||
Fast-moving motor | 250w 1360rpm | ||||
Dimensions (L × W × H) | 2500/2750/3250/3750/4750/5750/6750×1150×1700mm | ||||
Net weight | 2000/2300/2600/3000/3500/4000/4600kg | ||||
Standard accessories:1. φ250mm jaw chuck and chuck holder;2. Ground screw;3
