Hot Sale 4 Cylinder Lpg/cng Injector Rail for Sequential System
- Tianjing Shanghai Qingdao
- T/T L/C D/P D/A Credit Card PayPal
You May Like
-
Manufacturer Supply Hot Selling Common Rail Injector Nozzle
-
China OEM Cng Injection Rail and Valves
-
Cng/lpg Common Rail Injector for Conversion Kits
-
Manufacturer Hotsell Lpg Kit Fuel Injector Rail
-
LPG Fuel Injector
-
Valtek High Quality Gas Injector Rail/common Rail Injector /cng Injector Rail /common Rail Injector Spare Parts
Product Details
| Type | Fuel Pressure Regulator | Size | Standard Size | |
| Car Make | petrol Engine | OE NO. | Original | |
| Place of Origin | Shaanxi, China | Brand Name | YS | |
| Model Number | YS | Warranty | 2 Years |
Product Description
Hot sale 4 Cylinder lpg/cng injector rail for sequential system
Description:
According to the need of engine and burning gas ECU command, the injector injects fuel into cylinder quickly and accurately. Its advantages are small & compact shape structure, low noise, stable injection flow, easy to clean, stainless steel internal magnetic tube, excellent anti- friction property. it also can be regulated according to engine's working situation at any time.
Product properties:
1. Stable performance
2. Long working life & low noise
3. Adjustable flow
4. Simple structure of the internal design
5. Coil has excellent 30% flame retardant and antiknock performance
6. Insulation class: F grade
7. Steady connecting line interface
8. ED: 100%
9. Coil protection grade: IP65
10. Coil temperature resistant range: B.H
Specification Data:
item | Car LPG CNG injection-rail |
Specification | 3/4/6/8 cylinder |
working medium | car liquefied petroleum gas or compressed natural gas |
operating pressure | 0.5-2.5bar |
maximum pressure | 4.5bar |
maximum bearing pressure | 8bar |
operating voltage | DC 12V±10% |
coil resistance | 1Ω or 3Ω or 6Ω |
operating frequency | 150HZ |
air inlet | Φ16xΦ10 rubber tube |
air outlet | G1/8 thread, connector internal diameter Φ7 |
port thread | M12*1 |
nozzle flow range | 1.0~4.0mm(+0.04mm) |
temperature range | -20°C~120°C |
turn-on time | 2.5ms±5% |
off time | 2.0ms±5% |
flow error | ±0.4%L per 10L |
coil color | red, blue, black, orange available |
valve body color | white, black, golden, grey available |
application | the third generation system of LPG/CNG |
Can your factory supply OEM serive?.........................................
Yes, we can. Send us the sample or the detailed speicifications of the products you want to clone →calculate the cost of opening model →start to produce the sample for testing →continue to produce according to your feedback.
