Analogue TENS EMS Dual Medical Equipment

Analogue TENS EMS Dual Medical Equipment

Simple to Use with less breakdown possibility b/c LCD screen is eliminated.

Great pricing but with loads of function: including DUAL channel,DUAL function (TENS/EMS), THREE modes (cycle burst, continuous, modulated)

TECHNICAL SPECIFICATIONS:

FUNCTION MODES:

TENS:

B:  Cycle Bursts, 2Bursts/sec, 9pulses/Burst, 100Hz, width is adjustable.

C:  Continuous mode. Pulse rate, pulse width and intensity are full adjustable.

M:  Modulated Width. Pulse width is automatically varied in an interval of 6 seconds. The modulation range of pulse width is from setting value to 35% less than the control setting value. And then returns to the setting value. Rate, width and intensity are fully adjustable.

EMS:

S:  Synchronous.

A:  Alternation.

On Ramp:  Adjustable 1-8 seconds.

Cycle ON Time:  Adjustable 1-30 seconds.

Cycle OFF Time:  Adjustable 1-30 seconds.

Waveform:  Asymmetrical Bi-phasic square pulse.

Max charge per pulse:  21micro-coulombs maximum.

Voltage:  0-110 Volt (Open Circuit).

Power Source:  9-Volt Battery.

Dimensions:  95mm(H) × 61.5mm(W) × 26mm(T).

Weight: Approx. 125grams (battery included).

All electrical specifications are ±10% except the amplitude is +/-20% (500© load).
