CK6132A×450 CNC Lathe

1. Specifications

Items
unit
Specifications
Max. swing over bed
mm
φ320
Max. swing over carriage
mm
φ140
Max. length of work piece
mm
450
The main drive form

Independent spindle, frequency conversion stepless
Number of spindle speeds

Stepless
Spindle speed range
r/min
100-2000
Spindle bore
mm
φ42
Taper of spindle bore

MT5
Chuck diameter
mm
φ160
Power of the main drive motor
KW
3.0
Turret maximum stroke
mm
X:260       Z:450
Fast-moving feed
mm/mi
 X:6000      Z:8000
repeat positioning accuracy
mm
 X:0.01       Z:0.015
Workpiece accuracy

IT6-IT7
Workpiece surface roughness

Ra1.6
Tailstock quill diameter
mm
φ60
Tailstock quill stroke
mm
100
Tailstock quill taper

MT4
Standard configuration

Vertical four-station turret
Special optional

row or turret + row
Horizontal six-station turret or row
repeat positioning accuracy
mm
0.008
Arbor section
mm
16×16
Overall dimensions(L×W×H)
mm
1815*1165*1750
Net weight
Kg
1200
2.The main features
(1) cast iron integrated foot of the bed, the bed weight, rigidity, good stability.
(2) independent spindle frequency stepless speed, low noise, small vibration, high precision, energy saving and environmental protection.
(3) spindle with high speed and high precision bearings, processing performance and stability, good surface finish, high processing efficiency.
(4) bed rail VHF hardening, bed and slide saddle rail joint surface using a laminating process, reduce wear, prevent crawling, can achieve micro feed.
3, the main configuration
(1) control system optional: GSK, KND, Siemens, Fanuc Branch.
(2) chuck, tailstock Optional: manual, pneumatic, hydraulic, and so on.
(3) electric turret Optional: vertical four-station, six vertical position, horizontal six-station, eight-station, Pai knife.
(4) lubrication configuration: automatic oil lubrication system.
3.Uses
Suitable for precision machining of steel, non-ferrous metals and fast processing.

20 years experiences in cnc lathe machine reserach and production.

High reliability ,long lifetime to 10 years

One year warranty for whole machine,KND and GSK CNC System is 3 years

Professional engineer team to help you choose the suitable model and configuration.

Friendly factory price

Mechanical precision of our cnc lathe machine meet or exceed international standards

7X24 hours telephone or online technology support for free.
