Cheap Automated Metal Machine Tools

FOB Price

US$ 3,000 - 10,000 / Set

1 Set(Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition	New	Type	Horizontal
CNC or Not	CNC	Automatic Grade	Automatic
Max. Swing Diameter	360 400 500 600 700 800	Place of Origin	Shandong, China
Brand Name	HaiShu	Model Number	CK6136 40 50 60 80
Voltage	220/380	Power(W)	5.5
Dimension(LWH)	1815x1165x1750	Weight	1600-2500KGS
Certification	CE/ISO	After-sales Service Provided	Engineers available to service machinery overseas

Item	Unit	Technical parameters
		CK6136A	CK6140A		CK6140B
Max. rotation diameter over bed	mm	φ360	φ400		φ400
Max. rotation diameter over pallet	mm	φ245
Max. workpiece length	mm	750/1000
Main transmission form		Independent spindle		Independent spindle		Two gears
Spindle speed mode		Frequency stepless speed
Spindle speed range	r/min	200~2500		200~2500		60~1800
Spindle head form		6-A2
Spindle bore	mm	φ60		φ60		φ48
Spindle hole taper		MT6
Chuck diameter	mm	φ200		φ250		φ250
Main motor power	kw	5.5
Turret maximum stroke	mm	X:260 Z:760/1020
Fast-moving feed	mm/min	X:6000 Z:8000
Repeat positioning	mm	X:0.01 Z:0.015
Workpiece accuracy		IT6-IT7
surface roughness		Ra1.6
Dia. of tailstock quill	mm	φ60
Tailstock quill stroke	mm	120
Taper of tailstock quill		MT4
Repeat positioning accuracy	mm	0.008
Section of turning tool	mm	25×25		25×25
Size(L×W×H)	mm	2170/2420×1540×1650
Net weight	kg	1800/2000
