Manual Lifting Hoist
US$ 10 - 50
/ Piece
10 Pieces(Min. Order)
- shanghai port
- T/T L/C D/P D/A
You May Like
Product Details
| Condition | New | Place of Origin | Jiangsu, China | |
| Brand Name | Yi-Lift | Model Number | H21 | |
| Usage | Drywall Panel Hoist | Power Source | Hand Chain | |
| Sling Type | Chain |
Product Description
Latest technology offering world class performance and quality
- Compact design and light weight with special V class(100kgf/mm2) load chain made by PEWAG.
- Drop forged hooks
- Free from oil permeation.
- Conforms to CE safety standard.
| Model | H21-0521 | H21-1025 | H21-1525 | H21-2030 | H21-3030 | H21-5030 | |
| Capacity | (tonne) | 0.5 | 1 | 1.5 | 2 | 3 | 5 |
| Lifting Height | (m) | 2.5 | 2.5 | 2.5 | 3 | 3 | 3 |
| Test Load | (KN) | 7.5 | 15 | 22.5 | 30 | 45 | 75 |
| Effort to Capacity | (N) | 260 | 320 | 360 | 355 | 390 | 350 |
| Load Chain | DxT(mm) | 4.3x12 | 5.6x17 | 6.5x19 | 7.5x21 | 6.5x19 | 7.5x21 |
| Hand Chain | DxT(mm) | 4x19.5 | 4x19.5 | 4x19.5 | 4x19.5 | 4x19.5 | 4x19.5 |
| Headroom | No.of fall | 1 | 1 | 1 | 1 | 2 | 3 |
| Dimensions | A(Min.)(mm) | 275 | 310 | 340 | 380 | 480 | 555 |
| Net Weight | (kg) | 5.9 | 8.9 | 11.7 | 16.5 | 19.7 | 35.3 |
Larger hand chain 5x23.5 mm available.
Note: Specification and materials are subject to change without notice.
