Product Details
| Type | Other, Vulcanizer, Pillar, Frame, Jaw | Place of Origin | Shandong, China | |
| Brand Name | YaHua | Model Number | XLB | |
| Warranty | one year |
Product Description
China Best Price The Line of Conveyor Belt Vulcanizing Press
Main technical parameters
Type
| XLB-DQ400X400X2 | XLB-DQ400X400X2 | XLB-DQ600X600X2 | XLB-DQ750X850X2(4) |
Total Pressure(mn)
| 0.25 | 0.50 | 1.00 | 1.60 |
Plate Size(mm)
| 400X400 | 400X400 | 600X600 | 750X850 |
Daylight(mm)
| 125 | 125 | 125 | 125 |
Daylight No
| 2 | 2 | 2 | 2(4) |
Piston Stroke(mm)
| 250 | 250 | 250 | 250(500) |
Unit Area Pressure(kg/cm2)
| 20 | 31 | 28 | 25 |
Main Motor Power(Kw)
| 3 | 2.2 | 2.2 | 3 |
Overall Dimension(mm)
| 1300X800X1500 | 2400X550X1500 | 1401X680X1750 | 1900X950X2028 |
Weight(Kg)
| 1150 | 1300 | 3500 | 6500(7500) |
The line of Conveyor Belt vulcanizing presses are of high automation level and compact advanced structure, suitable to vulcanize giant conveyer belt such as nylon conveyer belt, common conveyer belt, anti-fire conveyer belt, wire rope conveyer belt etc.
The main machine is of frame structure and equipped with special purpose hydraulic unit. Both the hot plates and piston plunger are all made of superior material, they are accurately processed and have high etch and wear resistance. The control system has been taken up with PLC so as to realize multi program automatic control of curing process, for example, the temperature of the hot plates can be measured and regulated automatically. This will improve the control level and provide with high efficiency of production and low intensity of labor.
The main machine is of frame structure and equipped with special purpose hydraulic unit. Both the hot plates and piston plunger are all made of superior material, they are accurately processed and have high etch and wear resistance. The control system has been taken up with PLC so as to realize multi program automatic control of curing process, for example, the temperature of the hot plates can be measured and regulated automatically. This will improve the control level and provide with high efficiency of production and low intensity of labor.
The Line of Conveyor Belt Vulcanizing Press
According to your demand manufacture
various types of rubber machineries.
