Home > Products > laser cutting and engraving machine > Z&G CO2 Laser Tube 80w Cheap CO2 Laser Engraving Machine
Z&G CO2 Laser Tube 80w Cheap CO2 Laser Engraving Machine
- shanghai
- Credit Card PayPal
You May Like
-
VF 1612 Laser Cutting Machine
-
80 Watt Laser Engraving Machine Double
-
CNC Laser Cutting Machine Co2 Laser Cutting Machine With Co2 Laser Tube
-
Laser Cutting Machine Price SD-1326 100w CO2 Laser Tube for Plastic, Wood, Mdf,leather
-
VF-1610 CO2 Laser Cutting Engraving Machine With CO2 Laser Tube
-
ZG 3034 CO2 Laser Cutting Engraving Machine
Product Details
| Place of Origin | Shanghai, China | Brand Name | ZG |
Product Description
ShangHai ZhaoGuang length 1400mm 100W co2 laser tube
ZG serial co2 laser tube and product characteristics:
1. The pwer control system has exclusive automatic protection equipment to ensure the stability and safety of the mini laser cutter to the best.
2. LCD control panel in English, convenience of operating mini laser cutter.
3. Imported liner bearing with high engraving precision.
4. offline control system which can not only work without computer, but also connect to U disk, USB communication.
5. Imported metal mirrors, with good ability of reflection and focusing, long working life.
6. optional auto up&down work table, it is suitable for different thick material cutting and engraving.
7. Red light positioning system realizes the exact position without laser.
8. The auto focus system can be selected for precise focusing, and it can be equipped with rotary system, suitable for cylindrical and coniform pieces
Packaging & Delivery
Packaging Details: Standard Export Package( Export wooden packaging, fumigation board packaging)
Delivery Detail: 7-10 Days after received Payment
Z&G CO2 laser tube specification:
| Model | Specification | Rated power | Peak power | Triggering voltage | Working voltage | Working current | Catylist | Warranty(month) |
| G2 | 700/850*50mm | 40W | 45W | 22 | 15 | 18 | NO | 4 |
| G4 | 1000*50mm | 50W | 55W | 22 | 15 | 18 | 4 | |
| G6 | 1200*55mm | 60W | 70W | 24 | 18 | 20 | 4 | |
| G8 | 1600*60mm | 80W | 90W | 28 | 20 | 25 | 4 | |
| G10 | 1650*80mm | 100W | 110W | 30 | 23 | 28 | 4 | |
| Z2 | 1200*80mm | 80W | 90W | 24 | 18 | 23 | YES | 10 |
| Z4 | 1400*80mm | 100W | 120W | 24 | 20 | 26 | 10 | |
| Z6 | 1650*80mm | 130W | 150W | 28 | 23 | 28 | 10 | |
| Z8 | 1850*80mm | 150W | 170W | 30 | 25 | 30 | 10 | |
| Z10 | 2000*80mm | 170W | 180W | 32 | 25 | 32 | 10 |
Return and Maintain
Winthin 3 months after receiving the goods if there is any quality problem you can return the tube to us by the original box or another wooden box. We will responsible for maintainning or replacing a new tube for you. But you need to assume the shipping cost.
