Hydraulic plate rubber machine for Lab.

Specifications

  XLB-D350*350*2/0.25MN PLATE VULCANIZING

          MAIN TECHNICAL SPECIFITIONS

1.The nominal and mold force.........................................0.25 MN

2.The hot plate specifications....................................350*350mm

3.The hot plate unit area of pressure................................ 2.0MPa

4.Piston diameter.......................................................... ..152mm

5.Hydraulic cylinder number................................................ 1/set

6.Piston stroke.................................................................250mm

7.The hot plate distance................................................... 125mm

8.Work layer.....................................................................2  layer

9.Working liquid pressure............................................. .13.8MPa

10.Heating mode...............................................Electrocal heating

11.The highest tempreture...............................................200°C
12.The hot plate balance degree .................................≤0.06 mm

13.Temperature control precision.......................................± 5 °C
14.Control way.................................................... Semi-automatic

15.Motor power:............................................................2.2KW,1420r/min

16.Structure form..........................................................COLUMN

17.Total weight (about)........................................................1.0T
