Plate Vulcanizer/Rubber Production Mould Press Plant/Rubber Mat Manufacturing Machine
- 50 Set / Sets per Month
- Qingdao
You May Like
-
Tyre Curing Press/Auto Rubber Article Vulcanizing Press/Rubber Products Mould Press
-
XLB 80T Column Hydraulic Rubber Press Moulding Machine/Rubber Sports Protection Material Making Machine/Rubber Forming Machine
-
Natural Rubber Production Mould Press Plant/Rubber Mat Manufacturing Machine
-
Column Rubber Curing Press With The Best Seller Model/Auto Rubber Moulding Press/Rubber Shoe Sole Vulcanizing Press
-
Hydraulic plate rubber machine for Lab.
-
Four Column Type 2 Stations Rubber Shoe Sole Making Machine/Rubber Wheel Plate Rubber Vulcanizer/Curing Press
Product Details
| Condition | New | Place of Origin | Shandong, China | |
| Brand Name | Yahua | Model Number | XLB | |
| Voltage | According to your voltage | Power(W) | According to the machine | |
| Dimension(L*W*H) | According to the machine | Weight | According to the machine | |
| Certification | ISO9001 | Warranty | One year |
Product Description
Specifications
XLB Type Plate Vulcanizing Press1 Fully automaticed
2 PLC control
3 Deliver immediately
4 Competitive price
SUPERIOR QUALITY RUBBER VULCANIZER
1.Main uses
The Curing Press mainly works for the clampdown of rubber ,which can be used as normal hydraulic machine.
We have both column and framestructure .
2.Advantages:
1 Simple and convenient structure ,flexible operation,commodious space.The cylinder and plunger are made up of high –quality materials.
2 Hydraulic station and electric cabinet are Located in both sides of the main engine.
3 Conveniently operated.
4 Without oil spilling or off pressure.
5.Excellent reputation .
6 CE Standards
3. Technical Parameter as follows
Model | XLB-D1000*1000*1 | XLB-D/Q1200*1200 | XLB-D600*600 | XLB-D400*400*2 | |
1 | Norminal mouldning power(MN) | 2.50 | 3.15 | 1.60 | 0.5 |
2 | Plate size (mm) | 1000*1000 | 1200*1200 | 600*600 | 400*400 |
3 | Plate pressure (Mpa) | 2.5 | 2.19 | 4.4 | 3.1 |
4 | Piston diameter(mm) | 450 | 600 | 360 | 200 |
5 | Number of hydraulic cylinder (pcs) | 1 | 1 | 1 | 1 |
6 | Piston stroke(mm) | 300 | 800 | 300 | 250 |
7 | Distance between hot plate(mm) | 150 | 800 | 300 | 125 |
8 | Working layer number | 1 | 1 | 1 | 2 |
9 | Pressure of working fluid (Mpa) | 15.7 | 17.7 | 15.7 | 16.0 |
10 | Total heat power(KW) | 24 | 36 |
| 9.0 |
11 | Heat type | electricity | vapor/electricity | electricity |
electricity
|
12 | Maximum working temperature | 200°C | 200/170 °C |
200 °C
| 200 °C
|
13 | Configuration type | Frame | Frame | pillar |
pillar
|
Service after sale:
We give one year quality guarantee and long-term technical support. We also can train your workers for free. If you need, we can install and assemble the rubber hydraulic vulcanizing press machine in your workshop. And you should pay for the necessary costs, according to the international tradition.
Qingdao Yahua Rubber Machinery Co.,Ltd is 100% RUBBER MACHINERY manufacturer
Passed ISO9001:2008 certificate
