Home > Products > 2D Handheld Barcode Scanner > SC-162D 2D Laser Handheld Auto Scanner For All Cars
SC-162D 2D Laser Handheld Auto Scanner For All Cars
- Huangpu Guangzhou
- Credit Card
You May Like
Product Details
| Place of Origin | Guangdong, China | Brand Name | Shangchen | |
| Model Number | SC-182D |
Product Description
General
SC162D 2D barcode scanner, computerized image recognition system, brings about a new ear of 2D barcode decoding engines.
The 2D barcode decoder chip ingeniously blends technology and advanced chip design & manufacturing, which significantly simplifies application design and delivers superior performance and solid reliability with low power consumption.
The scanner supports all mainstream 1D as well as PDF417, QR code(M1/M2/Micro), Data Matrix and GS1-DataBarTM(RSS)(Limited/Stacked/Expanded versions).
Features
*2D Barcode Decoder Chip
The engine armed with the state-of-the-are 2D barcode decoder chip demonstrates unprecedented reading performance.
*Two-In-One Design
Seamless integration of CMOS image sensor and decoder board makes the engine small, lightweight and easy for integration.
*High Performance & Ultra-Low Power Consumption
The scanner can read 1D and 2D barcodes with a power consumption only one third that of a traditional scanner.
*All-Round Scanning Capability
It can read barcodes on virtually and medium-paper, plastic cards, mobile phones and LCD displays.
Specification
Performance | |||
Image Sensor | 752x480 CMOS | ||
Processor | 2D decoder chip 48MHz | ||
Illumination | Red LED 625±10nm | ||
Symbologies | 2D | PDF 417,Data Matrix(ECC200,ECC000,050,080,100, | |
140),QR Code | |||
1D | Code 128, EAN-13, EAN-8, Code 39, UPC-A,UPC-E, | ||
Codabar, Interleaved 2 of 5, ITF-6, ITF-14, ISBN, | |||
Code 93, UCC/EAN-128, GS1 Databar, Matrix 2 of 5, | |||
Code 11, Industrial 2 of 5, Standard 2 of 5, Plessey, | |||
MSI-Plessey,etc. | |||
Reading Precision | ≥5mil | ||
Depth of Field | EAN 13(13mil) | 55mm-185mm | |
Code 39(5mil) | 55mm-100mm | ||
PDF 417(6.67mil) | 40mm-130mm | ||
Data Matrix(10mil) | 40mm-135mm | ||
QR Code(15mil) | 40mm-160mm | ||
Symbol Contrast | ≥30% reflectance difference | ||
Scan Angle | Roll:360°, Pitch:±55°, Skew:±55° | ||
Field of View | Horizontal 36°, Vertical 23° | ||
Mechanical/Electrical | |||
Interface | TTL-232, USB(optional) | ||
| 0.76W | ||
Operating Vlotage | 303±10% VDC | ||
Current @3.3VDC | Rated Power Consumption | 230mA | |
Standby Current | 4mA(USB communication not supported);7mA(USB | ||
Communication supported) | |||
Sleep Current | <5uA | ||
Dimension | 21.17(W)x14.6(D)x11.52(H)mm | ||
Weight | 5.0g | ||
Environmental | |||
Operating Temperature | -20℃~+60℃ | ||
Storage Temperature | -40℃~+80℃ | ||
Humidity | 5%~95%(non-condensing) | ||
Ambient Light | 0~100000 lux(natural light) | ||
Accessories: Scanner, Manual, Cable, Neutral Packing Box
Individual Package: 1pc/box
Packed Size: 19*10.5*8cm
Packed Weight: 0.3kg
Outer Carton: 50pcs/carton
Packed Size: 43cmx40cmx56cm
Packed Weight: 16kg
SMT Department
Mold Department
Workshop
1.Cost Control - Good control of cost, would be able to provide you most competitive price.
2.Quality Control - Products passed CE,FCC,RoHs certifications.
3.Customer Service -We will reply your email or question within 24 hours.
4.Fast Delivery Time - 7 to 20 days upon order requirement.
1. OEM project is possible or not?
Yes, OEM project is welcomed.
2. How about the minimum order quantity?
Normally minimum order quantity is 100pcs/item.
3. Is that possible to silk customers' logo on products?
Yes, it is possible, and we will require the quantity is more than 200pcs.
4. How long will be the Warranty?
Normally we provide our products with 1 year warranty, it could be longer as well. However, price will be different when warranty period is longer.
5. Would you provide the RMA to custoemrs?
Yes, we will provide 1% free RMA to our customers.
