Home > Products > Hydraulic Tools > LSD High Quality10years QZD-240A hydraulic plier cable lug crimping tools open type 16-240mm2
LSD High Quality10years QZD-240A hydraulic plier cable lug crimping tools open type 16-240mm2
US$ 237 - 289
/ Piece
1 Piece(Min. Order)
- Ningbo/Shanghai
- T/T Credit Card
You May Like
-
LSD High Quality10years QZD-120A hydraulic plier cable lug crimping tools open type 16-120mm2
-
LSD High Quality10yearsHydraulic terminal crimping tool YQK-120 for copper and aluminum cable lugs 16~120mm2
-
LSD High Quality10yearsHydraulic terminal crimping tool YQK-240 for copper and aluminum cable lugs 16~240mm2
-
LSD High Quality10yearsHydraulic terminal crimping tool YQK-300 for copper and aluminum cable lugs 16~300mm2
-
LSD High Quality10years HT-131L hydraulic crimping tool for copper C clamps CCT60 to CCT240 hydraulic crimping tool
-
LSD High Quality10years HT-300 hydraulic crimping tool for copper C clamps CCT60 to CCT240 hydraulic crimping tool 16-300sq mm
Product Details
| Place of Origin | Zhejiang, China | Brand Name | LSD | |
| Model Number | QZD-240A | Type | Long Nose | |
| Material | Carbon Steel | Application | Crimping |
Product Description
*
QZD- 240A hydraulic plier cable lug crimping tools open type 16- 240mm2
hydraulic plier
Product Description
Tool Description:for QZD-300A hydraulic plier
| Product Name: | hydraulic plier |
| Model: | QZD- 240A hydraulic plier |
| Material: | Carbon Steel,Plastic |
| Application: | For cable lug |
| Crimping range: | 16- 240mm2 |
| AWG: | - |
| Length: | 690*250*120mm |
| Weight: | 4.5kg |
Features:
1.After many years of research and development, our company company has produced the brand new desigh "full automatic reset"
patented product for new generation of intelligent high-tech manual hydraulic press plier to make users do things with facility during their work and experience the advantage of hydraulic tool and its automatic device. Come on to have a try
2.German high and new technology, novel design of LISIDA
3.Full automatic reset can replace safety device and save the time of manual pressure release
4.Manual pressure release button can be loosened during the pressing course and can reset rapidly
5.Built-in combined type oil valve is convenient for maintenance with less malfunction;
6.It's head part adopts open type and bolt bar type, It is handy and solid and can rotate freely at 360 degrees of angle
| Item No | Crimping range | Crimping force | Stroke | Weight | Standard dies | Packing&Size | Type |
| QZD-120A | 16~120mm² | 7 ton | 13mm | 3.0kg | 16,25,35,50,70,95,120mm² | 545*240*130mm | (Bolt type) |
| QZD-240A | 16~240mm² | 10 ton | 16mm | 4.5kg | 16,25,35,50,70,95,120,150,185,240mm² | 545*240*130mm | (Bolt type) |
| QZD-300A | 16~300mm² | 10 ton | 16mm | 5.0kg | 16,25,35,50,70,95,120,150,185,240,300mm² | 690*250*120mm | (Open type) |
| QZD-400A | 16~400mm² | 10 ton | 16mm | 6.5kg | 16,25,35,50,70,95,120,150,185,240,300,400mm² | 690*250*120mm | (Open type) |
Tool Picture: for QZD-300A hydraulic plier
Packaging & Shipping
1.Trade Items Of Products
| Payment | L/C,T/T,Western Union |
| Port | Shanghai or Ningbo |
| MOQ | 100PCS |
| Supply Ability | 5000pieces/Month |
| OEM | Accept |
| Delivery | A.By Courier: 4-7 Working days by special offer |
| B.By Air: 7 Working days at appointed airport | |
| C.By Sea: 20-25 Working days at appointed port |
2.Packaging Of Products
A. Common Packing: Certain Pcs + Blister card + Export Carton
B. Customized Packing: OEM Label,Blister Card,Inner Box, etc. Experience production for 10years good qutails pliers hand crimping tools
Experience production for 10years good qutails pliers hand crimping tools
