Vandalproof MINI PTZ High Speed Dome Camera 700tvl

Camera

Optional Title

Dome camera’s title can be set

Effective Pixels

PAL:976(H)X582(V)    NTSC:976(H)X494(V)

Horizontal Resolution

Color: 650TVL; B/W: 700TVL

Scanning System

Interlacing

Electronic Shutter Speed

1/1s ~1/100,000s

Min. Illumination

Color: 0.01 Lux/F1.6; B/W: 0.001Lux/F1.6

S/N Ratio

More than 50dB

Video Output

BNC(1.0Vp-p/75Ω), PAL / NTSC

Camera Features

Day/Night

Auto(ICR) / Color / B/W

Backlight Compensation

BLC / HLC / DWDR (Digital WDR)

White Balance

Auto, ATW, Indoor, Outdoor, Manual

Gain Control

Auto / Manual

Noise Reduction

2D / 3D

Privacy Masking

Up to 24 areas

Lens

Focal Length

10x optical zoom

Focus Control

Auto / Manual

Close Focus Distance

10mm~1000mm

PTZ

Pan/Tilt Range

Pan: 0° ~ 360° endless; Tilt:0°~ 90(auto flip)

Manual Control Speed

Pan:0.6°~180°/s ,Tilt:3.5°~30°/s

Preset Speed

Max Pan: 200°/s; Max Tilt: 30°/s

Preset

220

PTZ Mode

4 Pattern, 8 Tour, Auto Pan, Auto Scan

Speed Setup

Human-oriented focal length/ speed adaptation

Power up Action

Auto restore to previous PTZ and lens status after power failure

Idle Motion

Activate Preset/Pan/Scan/Tour/Pattern if there is no command in the specified period

Time Task

Auto activation of Preset/Pan/Scan/Tour/Pattern by preset-time

Protocol

RS485 Protocols: PELCO-D, PELCO-P

IR Distance

40m-50m

Auxiliary Interface

RS485

1 port

General

Power Supply

DC12V/2A, AC24/3A(Optional)

Power Consumption

20W,43W (IR on, Heater on)

Working Environment

-40°C ~ 70°C / Less than 90% RH

Ingress Protection

IP66
