Home > Products > HD-SDI and HD-TVI Camera > Standard Broad lens Mini megapixel cctv Camera, 1080P Mini HD-SDI CAMERA
Standard Broad lens Mini megapixel cctv Camera, 1080P Mini HD-SDI CAMERA
- shenzhen
- Credit Card
You May Like
-
Pinhole Lens Mini Camera, 1080P Fixed Lens Mini HD-SDI security CAMERA
-
HD Pinhole Lens Mini Camera, 1080P Fixed Lens Mini HD-SDI CAMERA
-
2 Megapixel 1080P Full HD-SDI Color CCTV Security Camera HD SDI BOX Camera
-
Waterproof 2.8-12mm HD SDI Camera 2MP HD-SDI IR Bullet WDR dual voltage
-
2.8-12mm HD SDI Camera 2MP HD-SDI DOME Support WDR
-
HD SDI security camera Onvif 2.0,P2P Outdoor Full HD 1080P IP Camera
Product Details
| Place of Origin | Guangdong, China | Brand Name | JONEY | |
| Model Number | HDC-332A-1080P | Type | Other, Analog Camera, 1080p hd mini camera | |
| Style | Mini Camera | Sensor | Other, CMOS, 1/3 inch progressive scan 2.1 Mega Pixel Panasonic CMOS Sensor | |
| Technology | Pinhole | Special Features | Other, Mini HD-SDI CAMERA, WDR,3D-DNR,DEFOG |
Product Description
Specifications
1080P HD-SDI Mini cameraStandard Broad lens HD-SDI camera
3.6mm korean lens
True Day/Night Mechanical Lens Filter(ICR)
Standard Broad lens Mini megapixel cctv Camera, 1080P Mini HD-SDI CAMERA
Features: Mini HD-SDI CAMERA hd 1080p hd mini camera
• 1/3 inch progressive scan 2.1 Mega Pixel Panasonic CMOS Sensor
• 3M Pixels 3.6mm korean lens
• 1080p(1920*1080)@25/30fps
• Support WDR,3D-DNR,DEFOG
• OSD menu,Motion detection,Privacy Zone,HLC,BLC
• AWB/ATW/PUSH/MANUAL
• Min.Illumination:0.0003(Sens-up*1024x)
• True Day/Night Mechanical Lens Filter(ICR)
• TV Out(BNC) with NTSC/PAL Selectable
• Dual Output-Megapixel HD-SDI(BNC)&CVBS:1.0 Vp-p 750hm
• Power Supply:DC12V
• D:39(L)mm*39(W)mm*31(H)mm
• Weight:50g
• Color:Black
Specification: Mini HD-SDI CAMERA hd 1080p hd mini camera
Model No. | HDC-332A -1080P |
Image Sensor | 1/3 inch progressive scan 2.1 Mega Pixel Panasonic CMOS Sensor |
Effective pixels | 1920(H) x 1080(V) |
Scanning system | Progressive Scan |
Minimum illumination | 0.001 Lux |
Lens | 3M Pixels 3.6mm korean lens with ICR |
IR view distance | N/A |
WDR (Long and Short exposure) | OFF/ON(Level Adjustable) |
O.S.D | Built-in |
3D-DNR (3D Digital Noise Reduction) | OFF/ON(LOW/MIDDLE/HIGH) |
Sens-Up | OFF/ON |
Motion Detection | OFF/ON |
Privacy Zone | OFF/ON |
HLC | OFF/ON |
B.L.C. control | OFF/ON |
Defog | OFF/ON |
White balance | AWB/ATW/PUSH/MANUAL |
A.G.C | HIGH / LOW |
Electronic shutter Speed | AUTO/MANUAL/FLK |
Video output | HD-SDI(SMPTE 292M compatible) / CVBS:1.0 Vp-p Composite Signal (75ohm) |
Operation temperature | -10℃ - +50℃ |
Operation Humidity | Within 95% RH |
Power supply | DC12V(+/-15%) |
Power Consumption | 170mA / IR LED ON:400mA Max |
Dimensions (mm) | 39(L)*39(W)*31(H)mm |
Weight-Net (g) | 50g |
