HDPE PE LDPE PP Geo-net Production Line / HDPE Drainage Net Machine, Plastic Machniery
- Qingdao Port
- T/T Credit Card
You May Like
-
HDPE PE LDPE PP Geo-net Production Line / Plastic Net Machine
-
Geo-net Production Line / Plastic Net Making Machine
-
Plastic Turf Mat Production Line
-
PVC Plastic Calendering Floor Mat Machine / Production Line
-
PVC Calendering Floor Mat Machine / Production Line
-
Plastic Grass Mat Production Line /plastic Grass Machine
Product Details
| Condition | New | Application | Other, plastic net | |
| Plastic Processed | Other, LDPE PE | Screw Design | Single-screw | |
| Place of Origin | Shandong, China | Brand Name | Shine East | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Specifications
Plastic drainage net machine, plastic machinerywidth 2~5m
thickness 4.5~9mm
output 120~500kg/h
2~3 layer net
Geonet Production Line
plastic is HDPE, LDPE, PP as main raw material, adding antistatic agents, anti-aging agent of new polymer materials. For continuous production of plastic rigid flat net products, with different configurations of plastic netting production line can produce a function of different shapes, different sizes of mesh plastic net. Such as: two-way stretch net, packaging net, earthwork net, geogrid, air-conditioning networks, three-dimensional network, double-rib water network, grid, saucers mats, three-dimensional complex network of vegetation, mattress net aquaculture net .
Applications:
- When used in the embankment of highway and railway, the geo-net can allocate the loads effectively, improve the loading ability and stability of the roadbed, and prolong its service life. When used in the slope of highway and railway, the geo-net can prevent the rocks from falling, protect the water and soil, and beautify the environment. And when used in the reservoirs and protection of the rivers and dams, the geo-net is effective in preventing landslides. In the coastal engineering, its flexibility and good permeability can cushion the impact of wave energy.
Diamond net is mainly used in the fields of furniture, stock raising, etc., which can be used as supporting net or separation net.
Production line introduction
Technical parameter
Specification
Width
1000-2500mm
Production capacity
40-100kg/h
Power capacity
110kW
Outside dimension
15000×4500×4000mm
Equipment List
No. | Item | Unit | Data |
1 | Screw Diameter | mm | 65 |
2 | Length/Diameter | L/D | 28:1 |
3 | Screw Speed | r/min | 15-110 |
4 | Output | Kg/h | 30-120 |
5 | Whole Heating Power | Kw | 27 |
6 | Product Width | mm | 2000 |
7 | Pulling Speed | m/min | 0.4-4 |
8 | Main Motor Power(Extruder) | Kw | 37 |
9 | Motor Power(Mould Head) | Kw | 3 |
10 | Motor Power(Water Tank) | Kw | 1.1 |
11 | Motor Power(Rewinding) | N.m | 10 |
12 | Whole Weight of Product Line | Kg | 5200 |
13 | Measurement of Product Line(L*W*H) | m³ | 9*2.8*3 |
14 | Voltage | V | 380 |
15 | Frequency | Hz | 50 |
Process Flow
Material mixing---- Loading---- Heating and extruding----Molding---- Cooling----Cutting---Flating---- Haul off ----Winding---- Finished.
Material
PP or PE, material can be 100% recycled.
Technical Parameter
Model | S-2000 | S-2500 | S-3000 | S-4000 | |
Material | PE, PP | PE, PP | PE, PP | PE, PP | |
Screw Diameter mm | 65 | 80 | 90 | 120 | |
Die Head | Rotational die head | ||||
Total Power KW | 46 | 62 | 78 | 98 | |
Dimension M | 11×3.2×3.8 | 12×3.7×4.2 | 16×3.8×4.6 | 18×5.2×5.6 | |
Weight T | 4.2 | 5.6 | 7.8 | 8.8 | |
